Yarn Warping Machine

Request a Quote

View All: http://machinery-textile.com/6-1-yarn-warping-machine.html

Yarn warping machines carry out yarn wrapping for a variety of yarn types, including cotton yarn, polyester yarn, and artificial yarn. Yarn winding onto the beams prepares the yarn for the next processes. Beam size is 14 or 16 inches, or customizable upon request.

Parameters

Rear creel	140, 160, 192
Distance of creel	26cm
Beam	Diameter is below 400mm, the diameter of bore is 17 or 20mm, length 255mm
Variable speed	0~350 r/min (line speed: 1-600m/min)
Motor	Three- phase 1.5KW, 50 Hz, 380v ,3.68A, 1400r/min
Dimension of main machine	1600×700×1000 mm
Dimension of creel	2600×1850×2150 mm

Features

The yarn warping machine uses a variable frequency drive to ensure a stable start and flexible speed adjustment, ensuring a constant tension from beginning to end.
Driven by the friction between the pressure-adjusted roller and the beam: the friction is adjustable as needed to ensure a uniform yarn tension on the beam.
It is equipped with a digital counter meter to record the number of turns and adjust the length according to set requirements, thus avoiding yarn wastage.
W-type yarn buckles are used to adjust the left-right position and density according to requirements.
Auto stop motion in the event of yarn breakage makes operation easier and reduces failure rates.
