Electric Outboard Motor
Request a Quote
Your Motion
UNITE MOTOR electric outboard motors feature DC motor drive, simple structure, high safety, easy installation and dismounting and high portability, applicable to electric boats and electric yachts.
Technical Specifications
| Model No. | SP090G1 | SD128G1 |
| Input Power (kW) | 1 | 5 |
| Rated Voltage(V) | 48 | 48 |
| Efficiency (%) | 58 | 58 |
| Total Weight (Kg) | 8 | 18 |
| Thrusting Force (Kg) | 27 | 78 |
| Low Voltage Protection (V) | Li 42; PB 36 | Li 42; PB 36 |
| Shaft Length (mm) | 650/750 | 650/750 |
| Diameter of Propeller (mm) | 300 | 300 |
| Max Revolution of Propeller (RPM) | 1200 | 1200 |
| Control Mode | Tiller | Tiller |
| Rudder Movement | -50~ 50° | -50~ 50° |
| Shift | 4 shifts , Manual | 4 shifts, Manual |
| Protection Level | IP68 | IP68 |
| Working Temperature | 0~ 35℃ in water; -10~ 55℃ in air | 0~ 35℃ in water; -10~ 55℃ in air |
| Storage Temperature | -25~ 35℃ | -25~ 35℃ |
