Double Crank Presses
Request a Quote
Open Back Double Point Power Press with high performance
Features
- JIS I accuracy.
- Steel welded frame with high rigidity.
- Double crankshafts reverse rotated to eliminate lateral force.
- Motor with inverter.
- Combined wet friction clutch.
- Rectangular hexahedral lengthened gib.
- Hydraulic overload protector.
- Elec. adjustment with digital display.
- Lifting balance cylinder.
- Imported dual solenoid valve.
- Elec. forced grease lubrication.
- Balance cylinder: manual oil lubrication.
- Integrated panel (elec. cam included).
- PLC control.
- Ejector.
- Optional: air cushion, light curtain, automotive device.
Specifications
| Model | CP2-80 | CP2-110 | CP2-160 | CP2-200 | CP2-250 | CP2-315 | ||||||||
| Ⅰ | Ⅱ | Ⅰ | Ⅱ | Ⅰ | Ⅱ | Ⅰ | Ⅱ | Ⅰ | Ⅱ | Ⅰ | Ⅱ | |||
| Nominal | kN | 800 | 1000 | 1600 | 2000 | 2500 | 3150 | |||||||
| Nominal Stroke | mm | 5 | 3 | 5 | 3 | 6 | 3 | 7 | 3 | 7 | 3.5 | 7 | 3.5 | |
| Slide Stroke | mm | 160 | 90 | 180 | 110 | 200 | 130 | 250 | 150 | 280 | 170 | 280 | 170 | |
| SPM | Fixed (Optional) | min-1 | 55 | 70 | 50 | 60 | 45 | 55 | 35 | 45 | 30 | 40 | 30 | 40 |
| Variable | 40-75 | 55-90 | 35-65 | 50-80 | 30-55 | 40-65 | 25-45 | 35-55 | 20-35 | 30-45 | 20-30 | 30-40 | ||
| Max Die Height | mm | 350 | 400 | 450 | 500 | 550 | 550 | |||||||
| Die Height Adjustment | mm | 80 | 90 | 100 | 110 | 120 | 120 | |||||||
| Between Slide Center & Frame | mm | 310 | 350 | 390 | 430 | 470 | 480 | |||||||
| Bolster Area (FB×LR) | mm | 600×1600 | 680×1880 | 760×2040 | 840×2420 | 920×2700 | 940×2800 | |||||||
| Bolster Thickness | mm | 110 | 145 | 130 | 165 | 150 | 185 | 170 | 220 | 180 | 235 | 190 | 245 | |
| Slide Area (F·B×L·R ) | mm | 460×1200 | 520×1360 | 580×1500 | 650×1850 | 700×2100 | 700×2100 | |||||||
| Shank Hole (Dia.×Depth) | mm | 3-φ60×60 | 3-φ60×70 | 3-φ60×75 | 3-φ60×85 | 3-φ60×95 | 3-φ60×95 | |||||||
| Between Columns | mm | 1200 | 1450 | 1600 | 1900 | 2220 | 2400 | |||||||
| Main Motor Power | KW | 11 | 15 | 18.5 | 22 | 30 | 37 | |||||||
| Air Cushion (Option) | Air Bag Type Eject Force×Stroke×Qty. | KN | 40×80×2 | 40×80×2 | 60×90×2 | 80×90×2 | 100×100×2 | 100×100×2 | ||||||
| Cylinder Type Eject Force×Stroke×Qty. | mm | 40×60×2 | 55×70×2 | 80×80×2 | 100×90×2 | 125×100×2 | 125×100×2 | |||||||
| Outline Dimension (F·B×L·R×H) | mm | 2260×1750 | 2400×2040 | 2650×2220 | 2850×2620 | 3080×2960 | 2880×3040 | |||||||
| ×3100 | ×3260 | ×3580 | ×3980 | ×4320 | ×4320 | |||||||||
| Net Weight | Kg | 13000 | 16000 | 23190 | 30000 | 40000 | 42000 | |||||||
