Features of Concrete Pump Truck
1. Equipped with Japan Isuzu chassis and engine, and the extended cab for the operator to rest;
2. Its key components, such as transfer arm and outrigger, hydraulic system, electronic control system and pumping system are all from Germany;
3. Reasonable structure and easy maintenance.

Application of Concrete Pump Truck
As a key concrete equipment, this concrete pump truck is popularly used for the continuous concrete construction in the electricity, transport, road and urban construction fields.

Technical Parameter of Concrete Pump Truck
Model Chassis
model
Chassis drive mode Engine model Remote controller Tank capacity (L) Weight (kg) Max. speed (km/h) Overall dimension (L x W x H)(mm)
HJC5160THB 26M Shanqi SX1167DR511 4 x 2 ISME345 30 Japan 200 16000 78 9588 x 2490
x 3688
HJC5270THB 37M Isuzu CYZ51Q 6 x 4 Isuzu 6WF1A Germany HBC 700 27000 89 11850 x 2490
x 3940
HJC5320THB 45M Isuzu CYZ51Q 6 x 4 Isuzu 6WF1A Germany HBC 740 32000 85 12000 x 2500
x 4000
HJC5320THB 47M Isuzu CYZ51Q 6 x 4 Isuzu 6WF1A Germany HBC 740 32300 85 12000 x 2500
x 4000
HJC5390THB 48M Isuzu CYH51Y 8 x 4 Isuzu 6WF1D Germany HBC 740 39000 89 12807 x 2490
x 3970
HJC5391THB 49M Isuzu CYH51Y 8 x 4 Isuzu 6WF1D Germany HBC 820 39100 89 13949 x 2500
x 4000
HJC5391THB 51M Isuzu CYH51Y 8 x 4 Isuzu 6WF1D Germany HBC 820 39100 89 13949 x 2500
x 4000

Note: The above parameters are subject to change without prior notice.
