Track Roller for Komatsu D275 Bulldozer
Request a Quote
Focusing on 20-330 Ton Heavy Equipment Undercarriage Manufacturing
Delivering 1:1 OEM Alternatives to Global Distributors, Manufacturers, and Major Repair Workshops.
Delivering 1:1 OEM Alternatives to Global Distributors, Manufacturers, and Major Repair Workshops.
- Compatible Komatsu Excavator ModelsD275
- OEM Part NumbersD275 Track roller S/F (Single Flange)KOMATSU 17M-30-00320, KOMATSU 17M-30-01321, BERCO KM3595, BERCO KM3594, ITM A4027900M00
D275 Track roller D/F (Double Flange)KOMATSU 17M-30-01330, KOMATSU 17M-30-01331, KOMATSU 17M-30-00230, BERCO KM3597, ITM B4027900M00
Technical Specifications
- Description: Track Roller D/F (Double Flange), Track Roller S/F (Single Flange)
- Place of origin: China
- Brand name: PT'ZM
- Applicable machine model: D275
- Applicable machine brand: Komatsu
- Part number: 17M-30-01330, 17M-30-00320
- Certificate: GB/T19001-2016, ISO9001:2015
- Price: Negotiate
- Packaging method: Fumigate seaworthy packing
- Delivery time: 7-30 days
- Payment Terms: T/T, other terms negotiable
- Shipping terms: FOB, CIF, CFR
- Minimum order quantity: 1pc
- Supply ability: 100pcs/month
- Material: 35Mn2
- Manufacturing process: Forging
- Finish: Smooth
- Hardness: HRC48-55, depth 8-10mm
- Quality: Construction and mining operations, heavy duty
- Warranty period: 12 months
- After-sales service: Video technical support, online support
- Color: Yellow or customer required
- Application: Crawler bulldozer
Size Chart (unit: mm)
| D275 | A | B | C | D | E | F |
| 526 | 468 | 398 | 336 | 282 | 122 | |
| G | H | I | J | K | L | |
| 288 | 254 | 280 | 62 | 2-6.5 | 76 |
Extended Service Life and Superior Durability
Our track rollers are engineered with carefully selected materials and advanced processing techniques to ensure long-lasting performance:
- The roller is made from forged 40MnB2 high wear-resistant boron steel, heat-treated to a surface hardness of HRC 48-55 with a hardening depth of 8-10mm, delivering excellent wear resistance.
- The center shaft is forged from 42CrMo alloy steel, with a surface hardness of HRC 48-55 and core hardness above HRC 28, providing both wear resistance and high fracture toughness.
- The shaft surface is precision polished by CNC machining to minimize wear on the internal copper bushing during operation.
- Pure copper bushings are used internally to enhance wear resistance, while high-density sealing rings protect the internal structure from dust, sand, and moisture intrusion.
Track Rollers function The function of the track roller is to convey the weight of an excavator to the ground . When an excavator is run on uneven ground, track rollers carry a tremendous impact. Therefore, the support of track roller is huge. Moreover, if it is of poor quality and is often dusty, it needs a very good sealing to prevent dirt, sand and water from damaging it.
