1050 Aluminum Alloy
Request a Quote
Application
1050 aluminum alloy is used for the manufacture of heat sinks, chemical process plant equipment, food industry containers, pyrotechnic powder, lamp reflectors, cable sheathing, automotive industry, architectural and paneling, general sheet metal work, cabinets, vessels and appliances, PS CTP printing plate.
Aluminum alloy state, size and mechanical properties| Alloy | Temper | Thickness (mm) | Tensile strength (Mpa) | Elongation (%) | |
| Chinese standard | Value | ||||
| 1050 | O | ＞0.2-0.5 | 60-100 | 55-95 | ≥15 |
| ＞0.5-1.0 | ≥25 | ||||
| ＞1.0-4.5 | ≥30 | ||||
| H22 | ＞0.2-0.5 | 80-120 | 100-125 | ≥12 | |
| ＞0.5-1.0 | ≥15 | ||||
| ＞1.0-4.5 | ≥18 | ||||
| H24 | ＞0.2-0.5 | 95-130 | 120-150 | ≥6 | |
| ＞0.5-1.0 | ≥8 | ||||
| ＞1.0-4.5 | ≥10 | ||||
| H26 | ＞0.2-0.5 | 120-150 | 140-170 | ≥2 | |
| ＞0.5-1.0 | ≥4 | ||||
| ＞1.0-4.5 | ≥6 | ||||
| H18 | ＞0.2-0.5 | ≥130 | ≥170 | ≥2 | |
| ＞0.5-1.0 | ≥3 | ||||
| ＞1.0-4.5 | ≥3 | ||||
| 1050A | H18 | ＞0.2-0.5 | ≥140 | ≥170 | ≥1 |
| ＞0.5-1.5 | ≥2 | ||||
| ＞1.5-3.0 | ≥2 | ||||
