ANGEL Portable X-Ray Machine
Request a Quote
SHO-PXM01 Medical Imaging
Portable digital radiography unit for both human and veterinary use
With the ANGEL portable X-ray machine, you can easily perform both human and veterinary imaging. Designed for maximum portability, it features a built-in laser collimator for precise alignment. You’ll appreciate its 10.4-inch touchscreen and 17-inch × 17-inch wired flat panel detector, ensuring clear, high-quality imaging. It also comes with a Dell 15.6-inch laptop, giving you a complete, ready-to-use set. Housed in a durable aluminum casing, this portable X-ray machine is built for reliability and long-term performance.
Specifications
- Output: 560 W
- kV range: 40-70 kV
- mA range:2-8 mA
- mAs range: 10-2000 mAs
- Focal spot:0.4 mm
- Anode angle:12°
- Anode heat storage:4500J (6300HU)
- Input voltageCharger: 100-240V AC
- Dimension (L×W×H):263×210×210 mm
- Net weight: 3.5 kg
X-Ray Imaging
Chest radiograph
Limb radiograph
Veterinary radiograph
Applications
The ANGEL portable X-ray machine is used in a variety of medical and veterinary fields, including:
- Emergency room
- Orthopedics
- Physical examination
- Field training
- Operating room
- ICU
- Ambulance
- Animal husbandry
- Sports medicine
- Nursing home
- Rural medical visits
- Pet hospital
Need a versatile, ultra-portable X-ray machine? Contact us today for more details!
