Automatic Povidone-Iodine Gauze Packaging Machine
Request a Quote
- Model: PPD-PITDP10
- Gauze pad size: 10 × 10 cm or customized
- Pouch size: 15 × 15 cm or customized
- Packaging material specifications: outer roll diameter ≤ 350 mm, film width 250 mm
- Applicable gauze: 20–40 g/m² gauze rolls, outer roll diameter ≤ 600 mm, width 200 mm
- Production speed: 30–40 bags/min
- Power supply: 220 V, 50 Hz
- Installed power: 5 kW
- Machine dimensions: 4200 × 1250 × 2070 mm
- Weight: 1188 kg
Automatic povidone-iodine gauze packaging machines are designed as a packaging solution for (PVP-I) medical gauze pads, with in-line processing steps required before sealing. Before packaging, the gauze is impregnated with the povidone-iodine solution, layered with top and bottom materials, and cut into individual pads. These steps are carried out directly on the packaging machine, followed by four-side pouch sealing. Since all steps are handled on one machine, the (PVP-I) gauze does not need to be moved between processes, making packaging more stable and easier to keep clean.
Features- Suitable for automatic packaging of povidone-iodine gauze, petrolatum gauze, and paraffin gauze dressings
- Supports different pouch structures, including paper-film and paper-paper combinations, depending on packaging requirements
- Uses four-side sealing to ensure secure and consistent pouch packaging
