Frame Style Vulcanizing Press

Request a Quote

View All: http://vulcanizing-en.com/1-4-frame-style-vulcanizing-press.html

BELT VULCANIZING EQUIPMENT

Lightweight frame press for quick and easy splicing process

Minimum Vulcanization Width: 600mm

Maximum Vulcanization Width: 2150mm

The high-performance aluminum frame vulcanizing press is engineered for quick, simple, and efficient conveyor belt splicing. Its lightweight yet durable construction makes it ideal for on-site work and frequent repositioning. Each unit features integrated end handles and positioning rings (for larger models), allowing operators to easily align the press at the splice location. The TW Series requires no on-site assembly, consisting of just two main components (top and bottom), and weighs only one-third of a conventional vulcanizing press. This design makes it especially suitable for maintenance teams that need mobility, speed, and ease of use without sacrificing performance.

Applications

The frame-style vulcanizing press is suitable for splicing and repairing EP conveyor belts, nylon belts, cotton canvas belts, and conveyor belts with steel cable cores. It is widely used in industries such as mining, metallurgy, ore terminals, grain terminals, building materials, cement, chemical processing, coal-fired power plants, and tunnel engineering.

Specifications

EPN - 100 PSI - Rhomboid Models (all platens built on a 22 degree bias with a “left hand” lead.)
Model	Heating Plate Size (mm)	Belt Width (mm)	Total Weight (kg)	Overall Height (mm)	Overall Width (mm)	Overall Length (mm)	Components
Model	Heating Plate Size (mm)	Belt Width (mm)	Total Weight (kg)	Overall Height (mm)	Overall Width (mm)	Overall Length (mm)	Pump	Control Box
	480×760	600	161	405	495	1460	1	1
	710×760	600	175	405	708	1460	1	1
	480×940	800	204	455	495	1640	1	1
	710×940	800	230	455	708	1640	1	1
	480× 1090	900	209	480	495	1790	1	1
	710× 1090	900	238/285	480	708	1790	1	1
	480× 1220	1000	218	480	495	1920	1	1
	710× 1220	1000	284	480	708	1920	1	1
	330× 1420	1200	159	535	355	2120	1	1
	480× 1420	1200	290	560	495	2120	1	1
	480× 1575	1350	322	585	495	2275	1	1
	710× 1420	1200	375	560	708	2120	1	1
	480× 1625	1400	335	590	495	2325	1	1
	710× 1625	1400	435	635	708	2325	1	1
	480× 1880	1600	408	635	495	2580	1	1
	710× 1880	1600	536	685	708	2580	1	1
	480×2135	1850	472	710	495	2835	1	1
	560×2135	1850	548	760	569	2835	1	1
	710×2135	1850	698	750	708	2835	1	1
	480×2285	2000	550	780	495	2985	1	1
	480×2440	2150	720	815	495	3140	1	1
	480×760	600	161	405	495	1460	1	1
	710×760	600	175	405	708	1460	1	1
	480×940	800	204	455	495	1640	1	1
	710×940	800	230	455	708	1640	1	1
	480× 1090	900	209	480	495	1790	1	1
	710× 1090	900	238/285	480	708	1790	1	1
	480× 1220	1000	218	480	495	1920	1	1
	710× 1220	1000	284	480	708	1920	1	1
	330× 1420	1200	159	535	355	2120	1	1
	480× 1420	1200	290	560	495	2120	1	1
	480× 1575	1350	322	585	495	2275	1	1
	710× 1420	1200	375	560	708	2120	1	1
	480× 1625	1400	335	590	495	2325	1	1
	710× 1625	1400	435	635	708	2325	1	1
	480× 1880	1600	408	635	495	2580	1	1
	710× 1880	1600	536	685	708	2580	1	1
	480×2135	1850	472	710	495	2835	1	1
	560×2135	1850	548	760	569	2835	1	1
	710×2135	1850	698	750	708	2835	1	1
	480×2285	2000	550	780	495	2985	1	1
	480×2440	2150	720	815	495	3140	1	1

Notes

EPN1956-TW, “EPN” refers to the manufacturer, while the model number indicates the heating plate dimensions in inches: 19 inches in length and 56 inches in width. “TW” stands for two-piece press. Unlike traditional vulcanizing presses, this model is simpler, more flexible, and easier to use.
No on-site assembly is required, the press consists of just two main components (top and bottom). Customers can choose to use a single unit or multiple units depending on the splice length. The standard heating plate length is 710 mm, with other options available including 355 mm, 455 mm, and 660 mm, to meet different operational needs.

Custom heavy-duty frames are available upon request for continuous workshop use or frequent repeat operations. Please consult your local EPNUO vulcanizer representative for details.Not all models include side handles. Models marked with an asterisk (*) come with side handles as standard. This adds 6 inches to the total width. Optional 1/8" (3 mm) aluminum plates are available for side-by-side press arrangements, provided upon request.

Features

EPNUO “pressure bag” for uniform pressure system across splice surface

Built-in cooling system within platens

Innovative silicone element fast heating system

Lightweight aluminum frame

EPNUO control panel for managing vulcanizing temperature

Utilizes innovative platen system that combines an extruded aluminum base, silicone heating element, and durable composite insulation. Each platen conforms to belt surface variations, ensuring uniform results.

Maximum temperature: 163°C (325°F)

Available in rhomboid or rectangular configurations

Upper and lower sections are made from durable yet lightweight aluminum, allowing for easy transport and quick positioning. Smaller models feature ergonomic carrying handles

Standard E4P-RS control unit compatible with 230V single-phase or three-phase operation

Optional touchscreen version includes LCD display for heating temperature and curing time, real-time data logging for temperature, pressure, ambient conditions, and operation records, and USB interface for exporting vulcanization data

Spare Parts

Air Pump
Control Box
