30kW-100kW Diesel Generator Set
Request a Quote
Yuchai Engine Series
Powered by Yuchai diesel engine
The Yuchai engine series diesel generator sets feature a robust construction with the body and cylinder head made from high-strength alloy cast iron. They incorporate an integral forged steel crankshaft and sliding bearings, making them compact, lightweight, and highly reliable. These sets are designed for long service periods, with an overhaul interval exceeding 12,000 hours. Highly regarded both domestically and internationally, these generators meet a wide range of customer requirements. Below are the specifications for our 30-100KW Yuchai engine series diesel generator sets.
30kW/38kVA
Diesel Generator Set with Yuchai Engine, DB-30GF
- Prime power: 30kW/38kVA
- Standby power: 33kW/41kVA
- Rated current: 54A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Yuchai YC4V55Z-D20
- Alternator: Stamford/Leroy Somer/Engga (optional)
50kW/63kVA
Diesel Generator Set with Yuchai Engine, DB-50GF
- Prime power: 50kW/63kVA
- Standby power: 55kW/69kVA
- Rated current: 90A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Yuchai, YC4D90Z-D25
- Alternator: Stamford/Leroy Somer/Engga (optional)
60kW/75kVA
Diesel Generator Set with Yuchai Engine, DB-60GF
- Prime power: 60kW/75kVA
- Standby power: 66kW/83kVA
- Rated current: 108A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Yuchai YC4A100Z-D25
- Alternator: Stamford/Leroy Somer/Engga (optional)
80kW/100kVA
Diesel Generator Set with Yuchai Engine, DB-80GF
- Prime power: 80kW/100kVA
- Standby power: 88kW/110kVA
- Rated current: 144A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Yuchai YC4A140L-D25
- Alternator: Stamford/Leroy Somer/Engga (optional)
90kW/112.5kVA
Diesel Generator Set with Yuchai Engine, DB-90GF
- Prime power: 90kW/112.5kVA
- Standby power: 100kW/125kVA
- Rated current: 162A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Yuchai YC4A180L-D20
- Alternator: Stamford/Leroy Somer/Engga (optional)
100kW/125kVA
Diesel Generator Set with Yuchai Engine, DB-100GF
- Prime power: 100kW/125kVA
- Standby power: 110kW/137.5kVA
- Rated current: 180A
- Rated voltage: 400V/230V Customized
- Frequency: 50Hz
- Engine: Yuchai YC4A180L-D20
- Alternator: Stamford/Leroy Somer/Engga (optional)
