GKM95P Mining Truck

Request a Quote

Website: http://sinomachhiglobal.com/14-4-tl875-mining-truck.html

Consulting Products Information

Technical Specification:

Model	GKM95P
Engine	YUCHAI 520HP
Gearbox	FAST 8DS260
Front Axle Capacity (t)	25
Drive Axle Capacity (t)	35 35
Lifting System	Front Lifting Cylinder
Tire	16.00-25 36PR
Standard Bucket Capacity (m³)	39
Drive Mode	6×4
Curb Weight (t)	32
Rated Payload Capacity (t)	62
Maximum Gross Machine Weight (t)	95
Overall Dimension (L×W×H) (mm)	9300×3500×4260
Inner Dimension of Container (L×W×H) (mm)	6400×3400×1750
Maximum Speed (km/h)	42
Maximum Gradeability (%)	30
Minimum Turning Radius (m)	12
Minimum Ground Clearance (mm)	435
Braking System	SORL System

Gallery

Brief Description

SINOMACH as a reliable heavy equipment company in China, is making construction equipment for road construction and foundation engineering with decades of experience, SINOMACH has been a high quality heavy equipment maker in China and provide construction equipment and engineering vehicle with resonable prices.
