Aluminum Window Profile
Because sliding aluminium window is aesthetic, corrosion resistant, windproof, waterproof and environmentally friendly, it is increasingly popular with users all around the world. Common sliding aluminum window includes sliding glass window, sliding back window, automatic sliding window, sliding storm window, interior sliding window, and more. The production of these windows all involves aluminum window profiles.
We are a China-based aluminum window profile manufacturer, founded in 1997. In order to improve the impact resistance and corrosion resistance of our products, we constantly introduce advanced processing equipment and detection facilities from Germany, Switzerland and France. Today, our aluminium window profiles are used extensively in various residential buildings and commercial buildings.
Powder Painted Aluminum Window Extrusion Profiles, 6063-T5 / T6
Material: 6063 6060 6061 6005 6082 T4 T5 T6 T66
Surface: Mill Finished, powder coating, chemical and mechanical polishing, sand blasting, satin, bronze, black, golden, silver, anodizing, electrophoresis
MOQ: 500 kg. Usually 12 tons for a 20 foot container; 24 tons for a 40 foot container.
EPE, wrapped with waterproof paper, pallet, wooden case.
Sample delivery time: Two weeks (one week for mould +one week making sample)
Maximum extruder machine: 4000 tons;
Minimum extruder machine: 500 tons
Order, Payment, Terms and Shipment
1. Minimum order: 500kg per trial order 1 piece of sample free of charge provided by approval and kept for future mass production.
2. Sample Lead Time: 25 working days (15 days for making the tool and 10 days for the production of samples. Before sending the samples to the customer, samples will be strictly tested by our lab.) Production Lead time: it depends on customer order quantity (30 working days after deposit).
3. Payment: (Negotiable)
4. Tooling: 100% prepaid by T/T.
5. Parts: 30% upon order confirmation and balance before delivery by T/T
Aluminum door and window profiles can be used as partitions in balconies, studies, kitchens, bedrooms, offices , bathrooms and almost any other space that you are trying to separate from another.
Primary Technical Data
1) Chemical composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
| 6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
| 6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
2) Mechanical property
| Alloy | Temper | Tensile strength | Yield strength | Elongation |
| 6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
| T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% | |
| 6061 | T6 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
1. Offer OEM service.
2. Surface Treatment: Mill finished, wooden finished, anodized, powder coated, printed, polished.
3. Our extrusion machines are available to produce the thinnest of aluminum profiles (0.3 mm).
4. Color Choice: any color you want for powder coated, but for anodized we have five color choices: Matte silver, silver, bronze, dark, champagne.
- HD60
- HD60
- HD60
- HD60
- HD60
- HD60
- HD60
- HD60
- HD60
- HD60
In addition to aluminum window profile, we also offer curtain wall aluminum profile, aluminum door profile, corner aluminum extrusion, etc. These products are accompanied by superior service, including a 10-year warranty and maintenance service. Hence, they are well received in the USA, Russia, France, Germany, Dubai, South Africa, Argentina, Vietnam, among others.
Thank you for your interest in our aluminum profile. If you have any questions or concerns, please feel free to contact us.
