SP-300 Series Single Phase Programmable AC Power Source

SP-300 Series Single Phase Programmable AC Power Source
Request a Quote
Website:
  • High Output Crest Factor
    The power source offer peak current that is 5~6 times of rated current, suitable for rectifying loads or circuits and motors with transient surge current.
  • Power Line Disturbance Simulation
    Multiple waveform editing modes are offered, to simulate various disturbances and certificating items, such as periodic power-off, voltage sag, transient peak or more complicated situations, widely applied in R&D labs, universities and certificating labs.
    LIST Mode
    LIST Mode
    PULSE Mode
    Voltage Sags/Voltage Spikes
  • Harmonic/inter-harmonic Simulation and Measurement Function
    Able for simulating harmonics/inter-harmonics of up to 40 orders at 50Hz or 60 Hz, measuring amplitude or percentage based on fundamental frequency voltage of harmonics of 2~40 orders, graphical display of harmonics measurement. Waveform synthesis editing is supported.
  • Parallel Connecting and Three Phase Output
    With optional synchronization connector, multiple units can be parallel or series connected, with up to 600V and 184A output. Or units can be connected for three phase output, setting a Master(A phase), and Slave1(B phase), Slave2(C phase), among which phase differences are kept 120°; voltage of each phase can be set independently or synchronized according to certain needs, to simulate phase-unbalance or phase-absence situations. Y- and Δ-type connections can be achieved to satisfy certain needs.
  • Different Versions for Different Needs
    • Specifications
    Model Voltage Current Power Standard Communication Interface Frequency Range Size
    SP300VAC600W 150V/300V 5.6A/2.8A 600VA RS232/RS485/USB 15~1200Hz 2U
    SP300VAC1000W 150V/300V 9.2A/4.6A 1000VA RS232/RS485/USB 15~1200Hz 2U
    SP300VAC1500W 150V/300V 13.8A/6.9A 1500VA RS232/RS485/USB 15~1200Hz 2U
    SP300VAC2000W 150V/300V 16A/8A 2000VA RS232/RS485/USB 15~1200Hz 3U
    SP300VAC3000W 150V/300V 27.6A/13.8A 3000VA RS232/RS485/USB 15~1200Hz 4U
    SP300VAC4000W 150V/300V 32A/16A 4000VA RS232/RS485/USB 15~1200Hz 4U
    SP300VAC5000W 150V/300V 46A/23A 5000VA RS232/RS485/USB 15~1200Hz 4U
    Model Voltage Current Power Standard Communication Interface Frequency Range Size
    SPS300VAC1200W-2-9 150V/300V 10.08A/5.04A 1200VA RS232/RS485/USB 15~1000Hz 9U
    SPS600VAC1200W-2-9 300V/600V 5.04A/2.52A 1200VA RS232/RS485/USB 15~1000Hz 9U
    SPS300VAC1800W-2-9 150V/300V 15.12A/7.56A 1800VA RS232/RS485/USB 15~1000Hz 9U
    SPS300VAC2000W-2-9 150V/300V 15.56A/8.28A 2000VA RS232/RS485/USB 15~1000Hz 9U
    SPS600VAC2000W-2-9 300V/600V 8.28A/4.14A 2000VA RS232/RS485/USB 15~1000Hz 9U
    SPS300VAC2400W-2-17 150V/300V 20.16A/10.08A 2400VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC3000W-2-9 150V/300V 24.84A/12.42A 3000VA RS232/RS485/USB 15~1000Hz 9U
    SPS300VAC3000W-2-9 150V/300V 24.84A/12.42A 3000VA RS232/RS485/USB 15~1000Hz 9U
    SPS600VAC3000W-2-9 300V/600V 12.42A/6.21A 3000VA RS232/RS485/USB 15~1000Hz 9U
    SPS300VAC4000W-3-17 150V/300V 28.8A/14.4A 4000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC4000W-2-17 150V/300V 33.12A/15.56A 4000VA RS232/RS485/USB 15~1000Hz 17U
    SPS600VAC4000W-3-17 300V/600V 14.4A/7.2A 4000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC4500W-2-9 150V/300V 37.26A/18.63A 4500VA RS232/RS485/USB 15~1000Hz 9U
    SPS300VAC6000W-4-17 150V/300V 49.68A/24.84A 6000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC6000W-3-17 150V/300V 43.2A/21.6A 6000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC6000W-2-17 150V/300V 49.68A/24.84A 6000VA RS232/RS485/USB 15~1000Hz 17U
    SPS600VAC6000W-4-17 300V/600V 24.84A/12.42A 6000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC8000W-4-17 150V/300V 57.6A/28.8A 8000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC8000W-3-17 150V/300V 57.6A/28.8A 8000VA RS232/RS485/USB 15~1000Hz 21U
    SPS600VAC8000W-4-17 300V/600V 28.8A/14.4A 8000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC9000W-4-17 150V/300V 74.52A/37.26A 9000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC10000W-4-17 150V/300V 82.8A/41.4A 10000VA RS232/RS485/USB 15~1000Hz 17U
    SPS600VAC10000W-4-17 300V/600V 41.4A/20.7A 10000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC12000W-4-17 150V/300V 86.4A/43.2A 12000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC12000W-4-21 150V/300V 99.36A/49.68A 12000VA RS232/RS485/USB 15~1000Hz 21U
    SPS300VAC15000W-4-17 150V/300V 124.2A/62.1A 15000VA RS232/RS485/USB 15~1000Hz 17U
    SPS300VAC16000W-4-21 150V/300V 115.2A/57.6A 16000VA RS232/RS485/USB 15~1000Hz 21U
    SPS300VAC20000W-4-21 150V/300V 165.6A/82.8A 20000VA RS232/RS485/USB 15~1000Hz 21U

    Show All
