UN0531 Fixed Focus Lens, 1' Sensor, 6.86mm, F2.2 Aperture

UN0531 Fixed Focus Lens, 1' Sensor, 6.86mm, F2.2 Aperture
Request a Quote

Video Conference Lens

  • 1-Inch large sensor for more light and details
  • 20MP ultra-hd resolution for crisp images
  • 127.6° ultra-wide field of view for full coverage

The UN0531 fixed-focus lens features a large 1″sensor, larger than standard formats, delivering exceptionally crisp and detailed 20 MP images. With a 127.6° diagonal field of view, the lens provides full-room coverage, ensuring all participants are clearly visible and the image remains sharp and true-to-life from edge to edge. Supported by autofocus technology, it automatically tracks and adjusts when speakers move within the room, maintaining continuous clarity and precision. Engineered for high-end video conferencing, remote collaboration, and professional B2B applications, the UN0531 offers reliable, ultra-clear optical performance.

Specification
  • Part Number: UN0531
  • Sensor Type: 1'
  • Focal Length: 6.86mm±5%
  • FNo.: 2.8±5%
  • Total Length: 52.13±0.3mm (at inf)
  • Mechanical BFL: 4.72±0.2mm (at inf)
  • Max Image Circle: ∅15.88mm
  • Optical FOV (D): 127.6°±3°(∅15.14mm)
  • Optical FOV (H): 111.1°±3°(∅13.2mm)
  • Optical FOV (V): 61.9°±3°(∅7.4mm)
  • Relative Illumination: 67%±5%
  • Max Chief Ray Angle: 11.1°±3°
