Gemstone Vision Inspection Machine
Request a Quote
Optical sorting machine with CCD cameras for the visual inspection of gemstones
The gemstone vision inspection machine is engineered for high-precision surface inspection of gemstones and related high-value materials. Using advanced CCD cameras and a precision belt feed system, this system ensures stable and accurate handling of delicate items. It is ideal for identifying minute defects or inconsistencies in cut, shape, or surface clarity, with a detection speed of at least 200 pcs/min and an inspection accuracy of ±0.01 mm.
Inspection Cases
Specifications
| General | Power | 1.8 kW | |
| Air pressure | 0.4-0.6Mpa,air inlet pipe Ø16mm | ||
| Machine dimensions | 1100(L)×1700(W)×1800(H)mm | ||
| Machine weight | 350kg | ||
| Working conditions | Less than 90% RH | ||
| Visual inspection | Inspection speed | Design speed: 80-3000 pcs/min | |
| CDD Camera | Image sensor | Basler (German) | |
| Resolution | 2560×1920,1280×1024 | ||
| Inspection accuracy | ±0.01mm | ||
| Lens | Optical lens | Custom lens | |
| Depth of field (DoF) | 0.2-3mm | ||
| Light source | AOI light source | ||
| Feeding | Precision belt feed system | Precision belt is made from special conductive material through integrated forming process,ensuring high accuracy (customized) | |
Types of Defects Detected
- Roundness Deviation
- Surface Haze
- Dimensional Deviation
- Tip Damage
- Crack
