Automatic Airline Tag Eyeleting Machine, LM-JY5 Manufacturer

Automatic Airline Tag Eyeleting Machine, LM-JY5

Request a Quote

View All: http://stringermachineinc.com/2-2-full-automatic-hang-tag-eyelet-punching-machine-lm-jy5.html

LM-JY5 automatic eyeleting machine is typically designed for attaching eyelets on A5 airline tags, the speed of machine reaches approximately 2000 pieces per hour. It requires only one person to operate, simple and easy to use, and offers high productivity.

Details

Specifications

Model	LM-JY5
Speed	2000-3000pcs/hr
Tag material	Paper tag, plastic tag
Tag thickness	150gsm-700gsm (for other thicknesses, machine is customizable per your sample)
Stacking height of paper tags	250mm
Min. tag size	50*100mm
Max. tag size	150*210mm
Tag shape	Rectangle, square, round, oval, and other regular shapes
Inner diameter of eyelet	2.6-6mm
Machine weight	250kg
Machine dimensions	98011501570mm
Power supply	220V, single phase, 50/60HZ
Power	0.75KW

Features

Automatic accomplishing of multiple processes in one pass, including tag loading, hole punching, eyelet attaching, tag collecting and counting;
Equipped with control system consisting of variable frequency drive, PLC control, touch screen and sensor;
Suitable for attaching eyelets on airline tags and other various tags where hole reinforcement is required;
Molds are can be changed easily, safe and reliable operation;
