Disk And Rim Assembly Welder

Disk And Rim Assembly Welder
Request a Quote

Taizhi’s assembly welders are designed for internal welding of 22.5 to 24.5-inch tubeless steel wheels.

Features
  • The weld joint’s strength and appearance quality satisfies international wheel industry standards.
  • This assembly welder has a vertical C-type structure, with a horizontal loading/unloading direction and an automatic turning angle adjustable within 0-60 degrees.
  • The electrical turntable contains a holder, feeding platform and unloading platform. Operators manually load and unload work pieces.
  • The work piece loads/unloads horizontally, is clamped using a pneumatic chuck and pneumatically reverses.
  • This welder uses an inverter for speed and PLC control. The parameters are easily set via touch screen.
  • The welding gun is pneumatically controlled and guided via a linear guideway with an adjustable up/down, left/right and front/back positioning.
  • All processes are sensor controlled.
  • Functions include a full welding process.
  • A 2mm welding wire is used and the flux is 431 with 60-80 mesh.
  • The equipment color is determined by users, or, if no color is specified, a cold white.
Equipment configuration
  • PLC: Japan Mitsubishi Fx1n30P
  • Speed controller with inverter: Taiwan HOLP0.75KW
  • Touch screen: Taiwan SANTENGD-37
  • Electrical parts: Siemens H40/8
  • Cylindrical welding gun lifting mechanism: DELIXI G80
  • Pneumatic chuck: Wuxi Jianhua 320
  • Casting aluminum reduction gear: Taizhou 50/90
  • Welder: Shuanghui NB-1000;
  • Linear guideway: Taiwan Acepillar HGW35
Technical parameters
  • Rated power 38kW
  • Rated primary voltage 380V
  • Phase number A.B.C.N
  • Duty cycle 60%
  • Rated welding current 1000A
  • Rated welding voltage 60V
  • Welding speed stepless control
  • Overall weight 2.0T
  • Efficiency 22.5-9.0inch wheel, 1 piece/ 2 min
