Semi-Automatic Pendulum Impact Testing Machine
Impact tester for defining the impact strength of metals and plastics
Applications
Ideal for testing the impact strength of metal and ceramic materials, with widespread use in industries such as metallurgy, ceramics, and mechanical manufacturing.
Evaluating the impact resistance of metals and ceramics under dynamic loads is essential for determining material durability, and this semi-automatic pendulum impact tester offers a reliable solution. The impact testing device is electrically controlled, allowing automated functions for pendulum lifting, impact, and release. It’s designed to utilize the remaining energy from broken samples to automatically prepare for the next test, making it highly efficient for laboratories that perform continuous impact testing. This feature is especially beneficial in industries such as metallurgy and mechanical manufacturing, where large volumes of impact tests are required.
Technical Specifications
| Impact energy | 150J, 300J |
| Pendulum lift angle | 150° |
| Distance from pendulum axis to impact center | 800mm |
| Impact speed | 5.4m/s |
| Sample support span | 40mm |
| Radius of curvature of supports | R1-1.5mm |
| Radius of impact knife | R2-2.5mm |
| Angle of impact knife | 16mm |
| Accuracy of angle | ±0.1° |
| Sample size | 10×10×55mm |
| Dimensions (L×W×H) | 2300×600×1400mm |
| Net weight | 550kg |
| Power supply | AC three phase 380V±10% 50HZ 5A |
| Working conditions | Environment without corrosive media, vibration and strong magnetic field interference |
Standards
- ISO 148-2:2016
Metallic Materials — Charpy Pendulum Impact Test — Part 2: Verification of Testing Machines - ASTM E23-2018
Standard Test Methods for Notched Bar Impact Testing of Metallic Materials - DIN EN ISO 148-2:2017
Metallic Materials — Charpy Pendulum Impact Test - BS EN ISO 148-2:2016
Metallic Materials — Charpy Pendulum Impact Test - ISO 148-1:2016
Metallic materials — Charpy Pendulum Impact Test — Part 1: Test Method - ASTM E23-2018
Standard Test Methods for Notched Bar Impact Testing of Metallic Materials - ISO 180:2019
Plastics — Determination of Izod Impact Strength - ASTM D256-10(2018)
Standard Test Methods for Determining the Izod Pendulum Impact Resistance of Plastics - ISO 179-1:2010
Plastics — Determination of Charpy impact properties — Part 1: Non-instrumented impact test - ASTM D6110-18
Standard Test Method for Determining the Charpy Impact Resistance of Notched Specimens of Plastics - GB/T3808-2002
Test Method of Pendulum Impact Testing Machine - GB/T229-2007
Charpy Pendulum Impact Test Method for Metallic Materials - GB/T 1843-2008
Plastics--Determination of Izod Impact Strength - GB/T 1043-1993
Plastics-Determination of Charpy Impact Strength
