QDPYW High-volume Backward Curved Centrifugal Blower Manufacturer

QDPYW High-volume Backward Curved Centrifugal Blower

Request a Quote

View All: http://industrialair-blower.com/1-2-5-belt-driven-centrifugal-blower.html

The high-volume centrifugal blower utilizes backward-curved fan blades driven by a high-powered motor to generate high airflow with high pressure and low noise. This equipment is especially suitable for exhausting smoke from kitchens and other applications to high altitudes.

Features

The pressure generated by the high-volume backward curved centrifugal blower is one to two times higher than that of traditional fume hoods and various kinds of centrifugal fans while providing the same amount of air flow. Therefore, this design can meet the requirements of commercial kitchen smoke exhaust systems.
The smoke exhaust effect of this centrifugal blower is two to three times better than traditional fume hoods and other centrifugal fan designs, proving itself as a superior alternative.
It has excellent smoke exhausting effects and can completely discharge the smoke and cooking oil fumes created by teppanyaki and other types of cooking that can create unclean air.
The centrifugal blower is equipped with conjoined oil bath bearings and a motor manufactured by trusted brands. It is durable and can provide a long service life up to 15 years.
This centrifugal blower is designed with a detachable structure making it convenient to transport, maintain, and clean. Oil stains are normal and do not require additional cleaning.

Specifications

	Power	Structure	Speed	Airflow	Pressure	Inlet(mm)		Outlet	Noise
	KW	Structure	r/min	m³/H	Pa	Round	Square	Square	Db
2.5#	2.2	Direct Drive	1450	5400	529	410	450 x 450	380 x 300	70
3#	3		1450	9660	622	480	520 x 520	450 x 370	72
3.5#	4		1450	15060	872	560	600 x 600	520 x 450	75
4#	7.5		1450	19860	1078	630	670 x 670	600 x 500	78
4.5#	15		1450	25800	1254	710	750 x 750	680 x 550	80
5#	18.5		1450	33600	1519	780	820 x 820	750 x 600	85
4#	5.5	Belt Drive	1329	15800-17860	848-775	630	640 x 640	600 x 500	72
4#	7.5		1450	18000-19860	1005-912	630	640 x 640	600 x 500	75
4.5#	7.5		1088	21800-23630	1180-1250	710	750 x 750	680 x 550	75
4.5#	11		1269	22000-25300	1200-1380	710	750 x 750	680 x 550	78
5#	11		1128	23600-29000	1450-1290	780	820 x 820	750 x 600	80
5#	15		1350	28800-33000	1300-1450	780	820 x 820	750 x 600	83
5.5#	15	Belt Drive	1208	35680-42300	1600-1450	860	900 x 900	830 x 660	85
5.5#	18.5		1289	41800-45600	1560-1248	860	900 x 900	830 x 660	88
6#	18.5		1088	45600-50650	1710-1680	930	940 x 940	900 x730	89
6#	22		1160	49800-5300	1790-1730	930	940 x 940	900 x730	91
6.5#	22		1027	53890-55800	1810-1700	1010	1050 x 1050	980 x 790	92
6.5#	30		1088	55600-59800	1710-1600	1010	1050 x 1050	980 x 790	93
7#	30	Belt Drive	932	63580-66000	1780-1680	1100	1150 x 1150	1050 x 850	95
7#	37		1036	71600-76800	1890-1830	1100	1150 x 1150	1050 x 850	96
8#	37		800	76100-80200	1830-1870	1250	1290 x 1290	1200 x 980	98
8#	45		900	79800-84860	1980-2100	1250	1290 x 1290	1200 x 980	98
