The U6B model mini linear actuator is a miniature version of the , and is specially designed for electric sofas. Its gear box is made of a metal material and has a small stroke of less than 150mm. It features a low noise, and it is small and easy to install, which makes it ideal for lighter loads that are no more than 100kg.

Appearance and size

Curve graph

① Load VS Curent; ② Current (A); ③ Load (N); ④ Load VS Speed; ⑤ Speed (mm/s)

Code of Parameters

code	Rated laod（N）			Rated current（A）	Rated speed（mm/s）
	Push	Pull			No-load(32VDC)	Full-load(24VDC)
Standard motor (2200RPM)
A	1500		1500	1.5	7.8		3.7
B	1000		1000	1.5	15.2		6.6
High Speed Motor(3800RPM)
E	2500		2000	2..8	9.3		5.2
F	2000		2000	3	13.2		6.9
G	1500		1500	4	26.4		10.8
Large motor(3400RPM)
H	1000		1000	3	24.5		16
J	3000		2000	4	12		7
Large motor(4500RPM)
K	3000		2000	4	16		7.5

Comment: when the voltage changes from 24V to 12V, the current will be doubled.

Customization parameter

1=12V
2=24V(standard)
1=white
2=Gunmetal grey

1=0°／180°
2=45°
3=90°
4=135°
1=Width 6.2mm, hole Φ6.4mm
2=Width 6.2mm, hole Φ8mm
3=Width 6.2mm, hole Φ6.4mm(standard)
4=Width 6.2mm, hole Φ10mm, tube Φ8mm

1=holeΦ6.4mm
2 =holeΦ8mm
3=clevis, slot 6mm, hole Φ6.4mm
4=clevis, slot 6mm, hole Φ8mm
5=clevis, slot 6mm, hole Φ10mm
6=holeΦ10mm(standard)
7=holeΦ10mm,tubeΦ8mm
8=Width 32mm, hole Φ10.2mm with plastic cap
1=Switches in both end off to stop(standard)
2=Switches in both end off to output signal and a third one off to stop
3=Switches in both end off to stop and a third one off to output signal
4=Switches in both end off to output signal
c=customization

1=no
2=Single Hall Effect Sensors
3=Dual Hall Effect Sensors
c=Customization
1=no
2=One two-cycle torsional spring
3=1.5m

1=0.5m
2=1m
3=1.5m
4=2m
5=3m
6=0.35m
7=0.75m
8=0.8m
1=Tined leads
2=01pin(standard)
3=Din 6pin
4=Y cable 01pin, Din 5pin female(0.5m)
5=V cable 01pin, Din 5pin female(0.35m)
6=Din 5pin
7=2pin VH-3.96MM
8=110 terminal
9=E cable, 01pin male，01pin female，5pin female
A=Three trailers，01pin male，01pin female×2，5pin female

1=straight
2=coiled
