FL/FS SAE Split Flange Clamp
Request a Quote
Application: for use with hydraulic braided hoses
Materials:- Stainless steel SAE split flange clamp
- Carbon steel SAE split flange clamp
| Part No. | Thread | Dimensions | Bolt | Pressure | ||||||
| E | A | B | d | h | M | N | MPa | |||
| 3000PSI | ||||||||||
| FL-08 | 1/2'' | 54 | 45.6 | 9 | 38.1 | 38.1 | 17.5 | M8×25 | 34.5 | |
| FL-12 | 3/4'' | 65 | 51.8 | 11 | 47.6 | 47.6 | 22.2 | M10×30 | | |
| FL-16 | 1'' | 70 | 58.4 | 11 | 52.4 | 52.4 | 26.2 | M10×30 | | |
| FL-20 | 1.1/4'' | 79 | 72.6 | 11 | 58.7 | 58.7 | 30.2 | M10×30 | 27.6 | |
| FL-24 | 1.1/2'' | 94 | 82.2 | 13.5 | 69.9 | 69.9 | 35.7 | M12×35 | 20.7 | |
| FL-32 | 2'' | 102 | 96.4 | 13.5 | 77.8 | 77.8 | 42.9 | M12×35 | | |
| FL-40 | 2.1/2'' | 114 | 108.2 | 13.5 | 88.9 | 88.9 | 50.8 | M12×40 | 17.2 | |
| FL-48 | 3'' | 135 | 130.6 | 17.5 | 106.4 | 106.4 | 61.9 | M16×50 | 13.8 | |
| 6000PSI | ||||||||||
| FS-08 | 1/2'' | 56 | 47.2 | 9 | 40.5 | 40.5 | 18.2 | M8×30 | 42 | |
| FS-12 | 3/4'' | 71 | 60 | 11 | 50.8 | 50.8 | 23.8 | M10×35 | | |
| FS-16 | 1'' | 81 | 69.6 | 13.5 | 57.2 | 57.2 | 27.8 | M12×45 | | |
| FS-20 | 1.1/4'' | 95 | 77.2 | 13.5 | 66.6 | 66.6 | 31.8 | M12×45 | | |
| FS-24 | 1.1/2'' | 113 | 95 | 17.5 | 79.3 | 79.3 | 36.5 | M16×55 | | |
| FS-32 | 2'' | 133 | 113.8 | 22 | 96.8 | 96.8 | 44.5 | M20×70 | | |
