3412T Natural Gas Generator(1000kw)
Request a Quote
Description
- Engine model: A12V190ZLT
- Rated power: 1000kW
- Rated voltage: 400V/230V
- Rated rpm: 1500r/min
- Rated current: 1804A
- Overhaul time: ≥25000h
Click Here to
Technical Parameters of Natural Gas Engine
| Model | A12V190ZLT |
| Code | 3012T |
| Type | 4-stroke, spark ignition and water-cooled, turbocharged, inlet air cooling, mechanical inter-mixed |
| Arrangement of cylinders | V shape, 60° angle |
| Number of cylinders | 12 |
| Diameter of cylinders | 190 mm |
| Stroke | 215 mm |
| Rated rev | 1500 r/min |
| Idle speed | 700 r/min |
| Rated power | 1100kW |
| Heat consumption | ≤11000 kJ/kw·h |
| Oil consumption | ≤1 g/kw·h |
| Cooling mode | Pressurized water cooling |
| Lubrication mode | Pressure and spray lubrication |
| Exhaust temperature | ≤650℃(before entering turbine) |
| Steady state speed governing rate | ≤5% |
| Overhaul time | ≥25000h |
| Starting type | Air/electric motor starting |
Technical Specs and Performances of Natural Gas Generator Set
| Generating set model | 1000GF—TK |
| Engine model | A12V190ZLT |
| Generator model | 1FC6504-4LA42 |
| Excitation | Brushless phase compound excitation(three-phase four-wire)automatic voltage regulation, F class insulation |
| Control panel type | KT1000A-1 |
| Rated power | 1000kW |
| Rated voltage | 400V/230V |
| Rated rpm | 1500r/min |
| Rated current | 1804A |
| Rated power factor | 0.8(lagging) |
| Starting mode | air /24 DC starting |
| Cooling water circulation system | Open type with heat exchanger |
| Overhaul time | ≥25000h |
CNPC JICHAI was formed in 1920, we are a prestigious brand in China and is a global leader in internal conbustion engine and generator set manufacturing. Our power solutions are designed to improve your performance and productivity.
