Interlock Sewing Machine, HW762T
Computerized direct drive flatbed flatlock machine with automatic thread trimmer
Presenting our new generation of intelligent interlock sewing machine by Hikari. This computerized flatbed interlock machine utilizes both needle and looper threads to create a single-sided chain stitch or a double-sided chain stitch (by flipping the fabric and continuously sewing on the reverse side) on the fabric's surface, effectively joining two or more layers of fabric.
| Model | Needle | No. of Needles | No. of Threads | Needle pitch | Stitch length | Presser foot lifting height | Differential ratio | Speed (S.P.M) | Dimensions |
| | UY128GAS#10S | 3 | 5 | 5.6 | 4.4mm | 5 | 0.5-1.3 | 6000 r/min | 700x410x670mm |
| | UY128GAS#10S | 3 | 5 | 6.4 | 4.4mm | 5 | 0.5-1.3 | 6000 r/min | 700x410x670mm |
| | UY128GAS#10S | 3 | 5 | 5.6 | 4.4mm | 5 | 0.5-1.3 | 6000 r/min | 700x410x670mm |
| | UY128GAS#10S | 3 | 4 | 5.6 | 4.4mm | 5 | 0.5-1.3 | 6000 r/min | 700x410x670mm |
| | UY128GAS#10S | 3 | 4 | 5.6 | 4.4mm | 5 | 0.5-1.3 | 6000 r/min | 700x410x670mm |
| | UY128GAS#10S | 3 | 5 | 5.6 | 4.4mm | 5 | 0.5-1.3 | 6000 r/min | 700x410x670mm |
-
-
Automatic Foot Lifter Equipped with an automatic foot lifter, providing ideal force distribution and minimizing mechanical damage, prolonging the sewing machine's lifespan.
-
-
Enhanced Aesthetics Achieve beautiful and refined flatlock stitches, elevating the overall appearance of your products.
-
-
LED Illumination Enjoy a clear and bright working environment with our built-in LED lighting, allowing you to focus on intricate work details.
-
-
Upgraded Performance with UTC The adoption of an upper thread trimmer component (UTC) enhances the machine's work efficiency and performance.
-
-
Versatility in Stitching Experience the convenience of dual usage, where the sewing machine is adaptable for both standard and rolled hems, expanding the range of products you can create.
-
-
Efficiency with Low Noise Operate with ease at 4500 rpm, achieving a low noise level, providing a quieter work environment.
-
-
Accurate Thread Trimming Our automatic thread cutting device ensures precise thread trimming, maintaining stable sewing performance.
