Vibrating Screen
The vibrating screen effectively vibrates in the direction vertical to thescreen plate. It is usedfor coarse screening of various kinds of pulp, like chemical pulp, semi chemical pulp, mechanical pulp and waste paper pulp. It can also be used for fiber recovery from rejectsand tailings in the pressure screen and separator. Reliable quality and reasonableprice have made our vibrating screen very popular in many countries like Ecuador, Panama
Specifications of Vibrating Screen
| Model | MZS1 | MZS2 | MZS3 | MZS4 | MZS5 |
| Capacity(t/24h) | 2~10 | 5~20 | 10~40 | 15~70 | 20~100 |
| Screening Area(m2) | 0.5 | 1 | 2 | 3 | 4 |
| Hole Dia(mm) | Φ1.2~Φ2 | ||||
| Slot Size(mm) | 0.5~0.8 | ||||
| Inlet Consistency (%) | 0.5~2 | ||||
| Motor Power(KW) | 2.2 | 2.2 | 3 | 4 | 5.5 |
