Spherical Tempered Glass

Request a Quote

View All: http://temperedglass-en.com/1-4-spherical-tempered-glass.html

Curved glass for glass dome buildings

Spherical tempered glass is a type of tempered glass with a spherical curvature. Its complex manufacturing process combines high strength, safety, and unique aesthetic appeal. It is widely used in architectural domes, observation decks, high-end lighting fixtures, and other applications requiring a distinctive design. Spherical tempered glass is ideal for iconic structures such as observatory domes and spherical exhibition halls.

Example Project:

Malong Grand Theatre – Spherical Design

Features

Mechanical Performance Advantages
- High Strength: After tempering, the bending strength reaches 120–200 MPa, which is 3 to 5 times stronger than regular glass, significantly improving impact resistance.
- Wind Pressure Resistance: The spherical structure evenly distributes loads, making it especially suitable for dome buildings, capable of withstanding strong winds or snow pressure.
- Thermal Stability: The tempering process reduces the risk of thermal expansion and cracking, allowing the glass to adapt to temperature changes ranging from -40°C to 300°C.
Safety Features
- Safe Breakage: When broken, the glass shatters into small, blunt-edged particles (complying with GB 15763.2 or EN 12150 standards), minimizing the risk of injury.
- Anti-Spontaneous Breakage Design: Through homogenization treatment (Heat Soak Test), the glass’s susceptibility to spontaneous breakage caused by nickel sulfide inclusions is reduced to below 0.1%.
Optical and Aesthetic Features
- Symmetrical Aesthetic: The spherical curvature creates a visually harmonious effect, making it ideal for iconic buildings such as observatory domes and spherical exhibition halls.
- Light Focusing/Scattering: Forward Application: The spherical shape can be designed as a focusing lens (e.g., for solar collectors).
  Reverse Application: By using frosted or coated finishes (such as AR coating), glare and distortion can be minimized.
Installation and Functionality
- Self-Supporting Potential: Properly designed spherical structures can reduce reliance on external frames, making them ideal for applications like glass domes.

Bring your vision of iconic architecture to life with our spherical tempered glass, combining strength, safety, and unparalleled aesthetic appeal. Perfect for observatory domes or exhibition halls, let’s make your project stand out with extraordinary design. Reach out now to explore the possibilities!
