Automatic Box Stitching Machine

Request a Quote

Website: http://cartonmachine-en.com/2-6-4-automatic-box-stitching-machine.html

Automatic folder stitcher machine for making corrugated boxes

Automatic box stitching machine uses computer control for one-touch job changeover and is equipped with an automatic feeding system. It supports both single-stitch and double-stitch modes, making it suitable for a wide range of carton production requirements.

Structure

Lead-Edge Feeder

Stitching Head

Stacker Section

Output Section

Output Section

Technical Specifications

Model	QH1226
	Gluer	Stitcher
Max. size (A B)x2, mm	2600
Min. size (A B)x2, mm	420	900
Max. A, mm	900
Min. A, mm	130	270
Max. B, mm	650
Min. B, mm	80	180
Max. size (C D C), mm	1200
Min. size (C D C), mm	170	300
Max. C, mm	350
Min. C, mm	50
Min. D, mm	100

Sample Images
