Heat Shrink Cable Repair Sleeve
Request a Quote
Our heat shrink cable repair sleeve is designed for the insulation, sealing, and protection of low voltage cable connections such as mining cables and offshore wind turbine cables, as well as electronic contacts that require regular inspections.
| Width (mm) | Wall Thickness (mm) | Length | |||
| As Supplied (≥) | After Recovery (≤) | As Supplied | After Recovery | ||
| Ø30 | 120 | 37 | 1.0±0.3 | 3.8±0.4 | 900 |
| Ø40 | 130 | 37 | 1.0±0.3 | 3.8±0.4 | 900 |
| Ø50 | 160 | 52 | 1.0±0.3 | 3.8±0.4 | 900 |
| Ø65 | 205 | 74 | 1.0±0.3 | 3.8±0.4 | 900 |
| Ø70 | 220 | 74 | 1.0±0.3 | 3.8±0.4 | 900 |
| Ø85 | 270 | 85 | 1.1±0.3 | 3.8±0.4 | 900 |
| Ø100 | 320 | 85 | 1.1±0.3 | 3.8±0.4 | 900 |
| Ø120 | 380 | 125 | 1.1±0.3 | 3.8±0.4 | 900 |
| Ø150 | 475 | 155 | 1.1±0.3 | 3.8±0.4 | 900 |
| Ø160 | 505 | 155 | 1.1±0.3 | 3.8±0.4 | 900 |
| Ø195 | 590 | 155 | 1.0±0.3 | 3.8±0.4 | 900 |
| Properties | Test Method | Performance |
| Tensile strength | GB040 | ≥12MPa |
| Ultimate elongation | GB1040 | ≥300% |
| Tensile strength after aging | GB7141/130℃, 168hrs | ±20% |
| Ultimate elongation after aging | GB7141/130℃, 168hrs | ±20% |
| Dielectric strength | GB1408 | ≥15Kv/mm |
| Volume resistivity | GB1410 | 1x10 11 Ω·cm |
