Plastic Bouffant Cap Making Machine Manufacturer

Plastic Bouffant Cap Making Machine

Request a Quote

View All: http://ultrasonicsew.com/5-2-1-plastic-bouffant-cap-making-machine.html

Description
The plastic bouffant cap making machine is primarily used to process 0.01~0.02mm thick plastic films, and 460~470mm wide raw materials. A single machine has multiple functions, making it easy to produce bouffant caps in various specifications, including lengths of 17”, 18”, 19”, 20”, and 21”, simply by changing the molds. The equipment runs in a stable manner, with its fastest production speed reaching 120 caps/minute, and a product qualification rate of more than 99%.

Production flow

Automatic feeding

plastic film binding and welding

plastic film folding

forming welding

cutting off

finished products output

Parameters

Power supply	220V
Power	3.0KW
Length of bouffant cap	20', 21' (other sizes can be customized)
Output capacity	80-120pcs/min
Overall dimensions	38008001100mm
Net weight	500KG

Features

Utilizing an aluminum alloy frame, this equipment has a solid, durable structure and a long service life.
With ultrasonic system, strong and stable in power, it can realize longtime continuous production.
Electronic counting, with function of automatic shutdown at the set output.
Easy operation, convenient maintenance.
If the cap strap is broken, it will automatically stop.
