High Speed Water Ink Printer Slotter Machine
HighSpeed Water Ink Printer Slotter Machine
The high speed water ink printer slotter machine with elegantappearance and high working efficiency and is applicable to common cartons orsmall-sized cartons. It consists of feeder, printer and optional slotter, so the machine canfinish printing and slotting of three-layer or five-layer corrugated cardboardat one time.
The high intensitywallboard of the high speed water ink printer slotter machine is made of HT250 material and comeswith a thickness of 40mm, as well as precisely processed by large machiningcenter. In addition, the transmission agent adopts large spiral angle helicalgearing with little noise and smooth gear transmission. All the dive gears aremade of forged steel and treated with hardening and enclosed spray lubrication.Moreover, the water ink printer slotter machine is also provided with high quality anilox roller used for printing.
Each section of the high speed water ink printer slotter machine adopts the electric clutch withalarm bell ringing continuously for caution to ensure the safety of workingstaff. The constant torque clutch motor can buffer the collision of each unitcaused by wrong operation. In addition, each working unit of the high speedwater ink printer slotter machine has auto return-to-zero function, and can operate precisely with littlewaste of cardboard. With the modular design, the user can also discretionarilydetermine the number of working sections.
Technical Parameters of the High SpeedWater Ink Printer Slotter Machine
Maximum machine speed:
100pcs/min (front edgecardboard feeding)
90pcs/min (after edgecardboard feeding)
Economical production speed:
80pcs/min (front edgecardboard feeding)
70pcs/min (after edgecardboard feeding)
Maximum paper feed size: 950mmX 2200mm
Minimum paper feed size: 290mm(full print) X 500mm
Maximum printing area: 950mm X2000mm
Overprint precision: ≦±0.6mm
Slotting and die-cuttingprecision: ≦±1.5mm
Standard thickness of printingplate: 7.2mm
As a professional high speedwater ink printer slotter machine manufacturer based in
