GC Series Jaw Crusher (European Type)

Request a Quote

Website: http://stonecrusher-en.com/european-jaw-crusher-gc-2-3.html

This EU type jaw crusher is used for coarse and medium crushing operations. The crusher machine integrates advanced crushing technology and manufacturing processes, offering unique advantages in structural design, performance, service life, and equipment maintenance. It is an excellent choice for efficiently crushing hard and highly corrosive materials. Currently, this crusher has become one of the most popular jaw crushers in the fields of highways, railways, airport runways, mining, building materials, metallurgy, and chemicals.

Applicable Materials

Metal Ores
Non-Metal Ores

Iron OreManganese OreChrome OreCopper OreLead-Zinc OreBauxiteNickel OreTin OreGold OreSilver OreTungsten OreMolybdenum Ore

LimestoneDolomiteMarbleCalciteGraniteBasaltSandstone
(Quartz Sandstone)Arkose
(Feldspathic Sandstone)River PebbleTuff

Features

Modular design and a weld-free structure, making the crusher lightweight and more resistant to impact.
Use of large, high-quality bearings, ensuring longer product lifespan and more reliable quality.
The eccentric shaft is made of heavy-duty forged alloy steel, and the front and rear frames are made of high-strength cast steel.
Optimized crushing mechanism that achieves the best bite angle and stroke, improving the crushing ratio.
Higher rotation speed, increasing throughput and the number of material crushing cycles, which significantly boosts capacity.
Quick discharge adjustment, with both hydraulic and mechanical types adjustable from both sides via wedge blocks.

Specifications

Model	Length L1 (mm)	Width W1 (mm)	Height H1 (mm)
GC80	3088	1998	1982
GC96	3342	2022	2040
GC106	3760	2022	2460
GC110	4298	2334	2740
GC125	4690	2776	3250
GC140	4818	2902	3412
GC150	5053	2822	3970
GC160	5424	3325	3930
GC200	5990	3825	4880

Dimensions

Technical Parameters

Model	GC80	GC96	GC106	GC110	GC125	GC140	GC150	GC160	GC200
Feed opening (mm)	800×510	930×580	1060×700	1100×850	1250×845	1400×1070	1400×1200	1600×1200	2000×1500
Discharging size (mm)	40-175	60-175	70-200	70-200	100-250	125-250	125-250	150-300	175-300
Capacity (t/h)	65-380	120-455	155-580	190-625	290-845	385-945	400-1050	520-1275	760-2000
Power (kW)	75	90	110	160	185	220	280	315	400

Projects

Aggregate Plant Project of China Gezhouba Group in Ding'an, HainanIron Ore Crushing Plant for Baowu Resources Company in Bomi, LiberiaAggregate Plant in Vung Tau, VietnamStone Crushing Plant for CR18G's South-to-North Water Diversion Project

In a limestone quarry aggregate production line, which crusher types are usually arranged for primary and secondary stages?

In limestone production lines, a jaw crusher is typically used for primary crushing, while an impact crusher is used for secondary or fine crushing, forming a stable aggregate grading.

For a limestone to manufactured sand project, what key equipment stages appear in searches?

Searches often focus on jaw crushers, impact crushers/cone crushers, VSI sand making machines, vibrating screens, sand washing, and recycling systems.

In building materials production, where limestone, gravel, and other materials need to be crushed for even gradation after coarse and medium crushing, can the high-performance jaw crusher meet the requirements?

The high-performance jaw crusher adopts a V-shaped deep cavity structure and a consistent stroke power design, which significantly increases the material bite angle and crushing ratio. This ensures uniform force distribution inside the chamber, thorough crushing, stable discharge particle size, and uniform gradation, making it suitable for direct adaptation to sand making or aggregate production processes.
