1838HE
Hydraulic Rock Drilling Unit
  • Impact Output Power: 19kW
  • Drilling Diameter: Ø45-102mm

The 1838HE hydraulic drifter features an efficient hydraulic dual buffering system and a floating shank adapter, which significantly improves the rock drill’s production capacity and tool economy. Its powerful stepless variable speed bidirectional rotation motor provides high torque output and excellent speed control. The independent lubrication of the front head and drive unit, paired with pressurized lubrication for the end and side bolts increases productivity and reduces maintenance downtime.

Product Parameters
Max. Impact Output Power 19kW
Impact Frequency 42-50Hz
Max. Impact Pressure 230bar
Impact Oil Flow 71-90L/min
Max. Rotation Torque 1550Nm
Rotation Speed 0-215rpm
Max. Rotation Pressure 200bar
Rotation Oil Flow 75L/min
Drilling Diameter Range 45-102mm
Compatible Shank Adapters T38/T45/T51
Operating Weight 174kg
Accessories

Spline wear sleeve

Piston

Shank

Shank bushing

Cylinder copper sleeve

Accumulator diaphragm
