1100 Aluminum Alloy

Request a Quote

View All: http://aluminum-alloys.com/1-1-2-1100-aluminum-alloy.html

1100 aluminum is an aluminum-based alloy in the commercially pure wrought family. With a minimum of 99.0% aluminum, it is the most heavily alloyed of the 1000 series and the mechanically strongest alloy in this series. It can not be strengthened by heat treatment and keeps the benefit of good ductility, formability, weldability and corrosion resistance. In addition, after anodizing, its corrosion resistance can be further improved and a beautiful surface is obtained.

Application

1100 aluminum alloy is commonly used for HVAC, heat shield, deep drawn applications, cosmetic bottle cap, heat exchanger fins, spun hollowware, dials and name plates, decorative parts, giftware, cooking utensils, rivets and reflectors, and sheet metal work.

Aluminum alloy state, size and mechanical properties

Alloy	Temper	Thickness (mm)	Tensile strength (Mpa)		Elongation (%)
Alloy	Temper	Thickness (mm)	Chinese standard	Value	Elongation (%)
1100	O	＞0.2-0.5	75-105	75-110	≥20
		＞0.5-1.0			≥25
		＞1.0-4.5			≥30
	H22	＞0.2-0.5	95-130	100-125	≥10
		＞0.5-1.0			≥12
		＞1.0-4.5			≥15
	H24	＞0.2-0.5	110-145	120-150	≥6
		＞0.5-1.0			≥8
		＞1.0-4.5			≥10
	H26	＞0.2-0.5			≥2
		＞0.5-1.0			≥3
		＞1.0-4.5			≥4
	H18	＞0.2-0.5	≥150	≥170	≥1
		＞0.5-1.0			≥2
		＞1.0-4.5			≥3
	H112	＞4.5-6.5	≥95	≥95	≥9
		＞6.5-12.5	≥90	≥90	≥9
		＞12.5-50	≥85	≥85	≥14
		＞50-80	≥80	≥80	≥20

Chemical composition

Si Fe	0.95
Cu	0.05-0.20
Zn	0.1
Mn	0.05
Al	99
