Welding Equipment

Your welding application needs are our concern, satisfying your challenges with proven performance

  • Advanced IGBT inverter &MCU digital control: provides stable performance, reliability and high consistency.
  • Portable & lightweight: this welder is easy to operate and carry.
  • Wide range of input voltages: 155-265V (1ph) 50/60HZ.
  • Generator compatible: The MMA welder type B will be able to operate when powered by a generator.
  • Premium welding performance: support welding rods with a maximum diameter of 1.6mm (1/16") or 5.0mm(3/16"). The MMA welder can weld workpieces with a minimum thickness of 0.8mm. Good performance on various types of welding rods, such as E7018, E6010, E6011, E6013, E308, etc.
Model Power Voltage No-load Voltage Efficiency Rated Input Power Output Current Range Duty Cycle Electrode Diameter Weight Dimension
ARC120B 230V土10% 50/60hz (1ph) 75V 85% 5.5KVA 10-120A 60% 1.5-3.2mm (1/8") 2.8kg 28*13.3*19cm
ARC140B 230V土10% 50/60hz (1ph) 75V 85% 6.1KVA 10-140A 60% 1.5-3.2mm (1/8") 3.0kg 28*13.3*19cm
ARC160B 230V土10% 50/60hz (1ph) 75V 85% 6.9KVA 10-160A 60% 1.5-4.0mm (5/32") 3.6kg 31.5*13.3*22cm
ARC180B 230V土10% 50/60hz (1ph) 75V 85% 8.2KVA 10-180A 60% 1.5-5.0mm (3/16") 4.0kg 31.5*13.3*22cm
ARC200B 230V土10% 50/60hz (1ph) 75V 85% 9.6KVA 10-200A 60% 1.5-5.0mm (3/16") 4.5kg 31.5*13.3*22cm
Features
  • Advanced IGBT inverter &MCU digital control

    Provides stable performance, reliability and high consistency.

  • Portable & lightweight

    This welder is easy to operate and carry.

  • Wide range of input voltages

    155-265V (1ph) 50/60HZ.

  • Generator compatible

    The MMA welder type B will be able to operate when powered by a generator.

  • Premium welding performance

    Support welding rods with a maximum diameter of 1.6mm (1/16") or 5.0mm(3/16"). The MMA welder can weld workpieces with a minimum thickness of 0.8mm. Good performance on various types of welding rods, such as E7018, E6010, E6011, E6013, E308, etc.

  • Hot start

    Provides very easy, quick and reliable arc starts upon contact with the workpiece.

  • Anti-stick

    Avoid electrode sticking in the workpiece during welding, ensures no sticking and smooth welds.

  • Built-in arc force

    Provides smooth and continuous arc, ensures stable welding, and maintains deeper penetration.

  • Safety protection

    The welder is equipped with automatic compensation for overload, overheating protection, voltage fluctuation, and short circuit protection.

  • Lift TIG capabilities

    Integrated lift-TIG functionality enables TIG welding using argon gas. You can choose stick or lift TIG mode as you want.

  • Optional sizes come with

    28*13.3*19cm or 31.5*13.3*22cm.

Applications
  • Welding equipment for minor construction projects
  • Home decoration industry welding machine
  • Welding equipment for farm and ranch
  • Portable welder for repairs and home DIY
Standard Accessories
  • Electrode holder with cable
  • Earth clamp with cable
Optional Accessories
  • Plastic tool box
  • Welding mask
  • Wire brush
FAQs
The manual welder can handle workpieces with a thickness range of 0.8-13 mm.
MMA Welder Type B is suitable for various types of welding rods such as E7018, E6010, E6011, E6013, E308, and more.
MMA Welder Type B can achieve welding of stainless steel, iron, alloy steel, and other materials.
Yes, it can be used in conjunction with a power generator, as a movable welding machine.
SONSCN has over 20 years of experience as a professional welding equipment manufacturer. We not only provide welding machines, but also offer related welding equipment accessories.
Yes, we can provide customization for welding machines and related OEM services, such as welding machine color, size, appearance, packing, performance, parameters, etc., to meet the needs of welding processes.
