316 Stainless Steel Gate Valve
Request a Quote
- Working pressure: 125 PSI WAP, 200 PSI CWP
- Max. temperature: 180℃/350°F
- ASTM A351 CF8M stainless steel body and bonnet, PTFE Teflon packing
- Connection: Threaded and socket weld
- Non-rising stem, round metal handle
- The gate valve is a valve in which the flow of fluid is controlled by moving a wedge or disc-shaped gate.
- Gate valves are used for shut off applications in a variety of pipelines. In the open position, the gate valve provides very little restriction to the flowing fluid. Thus, the primary advantage of the gate valve is low pressure drop.
Specifications
Inch/Metric(mm)
| Item # | Size | DN | L | W | D | H | ||||
| inch | mm | inch | mm | inch | mm | inch | mm | |||
| SSGV-50 | 1/2" | 15.00 | 2.66 | 67.5 | 0.12 | 3 | 2.80 | 71 | 3.66 | 93 |
| SSGV-75 | 3/4" | 20.00 | 2.76 | 70 | 0.12 | 3.1 | 2.44 | 62 | 4.17 | 106 |
| SSGV-100 | 1" | 25.00 | 3.03 | 77 | 0.16 | 4.1 | 2.95 | 75 | 4.57 | 116 |
| SSGV-120 | 1-1/4" | 32.00 | 3.43 | 87 | 0.19 | 4.8 | 2.95 | 75 | 4.80 | 122 |
| SSGV-150 | 1-1/2" | 40.00 | 3.94 | 100 | 0.19 | 4.8 | 3.74 | 95 | 5.67 | 144 |
| SSGV-200 | 2" | 50.00 | 4.33 | 110 | 0.22 | 5.6 | 3.74 | 95 | 5.71 | 145 |
| Part # | Part Name | Material |
| 12 | Screen | SS304 Stainless Steel |
| 11 | Washer | SS304 Stainless Steel |
| 10 | Name plate | AL. |
| 9 | Handle wheel | AL. |
| 8 | Stem | SS316 Stainless Steel |
| 7 | Gland nut | 316 Stainless Steel |
| 6 | Gland bush | SS316 Stainless Steel |
| 5 | Packing | PTFE |
| 4 | Bonnet | 316 Stainless Steel |
| 3 | Gasket | PTFE |
| 2 | Disc | 316 Stainless Steel |
| 1 | Body | 316 Stainless Steel |
