Haynes 230 (UNS N06230) High-temperature alloy
Request a Quote
Features
HAYNES 230 is a useful material that features high-temperature strength and outstanding resistance to oxidizing environments up to 1149°C for long time exposure. It is easily fabricated and has very good forming and welding characteristics.
Product Form
| Products | ASME Standard | ASTM Standard | AME Standard |
| Plate, Sheet, Strip | B575 | SB575 | SB575 |
| Bar | B622 | SB622 | SB622 |
| Forging Part | B619.B626 | SB619.SB626 | SB619.SB626 |
| Wire | B574 | SB474 | - |
| Welded ND Pipe | B574 | SB474 | - |
| Seamless Pipe | B574 | SB474 | - |
| Welded Pipe | B574 | SB474 | - |
Chemical Analysis
| % | Ni | Cr | W | Mo | Co | Fe | Mn | Si | C | Al | P | S | La | B |
| Min. | Balance | 20 | 13 | 1 | - | - | 0.3 | 0.25 | 0.2 | - | - | 0.005 | - | |
| Max. | Balance | 24 | 15 | 3 | 5 | 3 | 1 | 0.75 | 0.15 | 0.50 | 0.03 | 0.015 | 0.05 | 0.015 |
Physical Properties
| Density | 8.97G/CM3 |
| Melting Range | 1301-1371℃ |
- Applications
- Gas turbine components
- High temperature bellows
- Furnace components
- Combustion cans
- Power plant
