CL-3	Elevator Car Ceiling Applicable for wide car
Car Ceiling	Painted Steel Plate *
Lighting	Indirect lighting of plate block type throughacrylic transparent mirror faceplate, translucent mirror faceplate, andhalf-slotted lighting is adopted on both sides.
Ventilation Device	Painted steel plate grill ventilation andcross-flow fan
Handrail	Stainless Steel Flat Handrail
Car Floor	Parquet marble pattern shall be provided by customer.

Note:
For wide car series, car inside height is standard, 20mm sink of car is standard configuration. When the car platform sinks 20mm, no decoration floor is provided, so customers can decorate with marble stone on their own.
Color number is selected and determined according to SMEC decoration color boards.

Material Comparison Table

Item	Material							Notes
Car Wall and Car Door	Film Paste Plate, Painted Plate, Hairline Stainless Steel Plate, Mirror Stainless Steel Plate, Hairline Etched Stainless Steel Plate, Mirror Etched Stainless Steel Plate, Metallic Paint Coating Stainless Steel Plate, Titanium Coating Painted Plate, Vibration Finish Stainless Steel Plate, Sand Pattern Stainless Steel Plate, Vibration Finish Etched Stainless Steel Plate, Sand Pattern Etched Stainless Steel Plate, Titanium Coating Hairline Stainless Steel Plate, Titanium Coating Mirror Stainless Steel Plate, Titanium Coating Vibration Finish Stainless Steel Plate, Titanium Coating Sand Pattern Stainless Steel Plate, Titanium Coating Hairline Etched Stainless Steel Plate, Titanium Coating Mirror Etched Stainless Steel Plate, Titanium Coating Vibration Finish Etched Stainless Steel Plate, Titanium Coating Sand Pattern Etched Stainless Steel Plate							For wide car.
	Painted Plate, Hairline Stainless Steel Plate							For deep car.
Mirror	Front Half Mirror							Optional
Kick plate	Polyvinyl resin kick plate（Dark-grey）							Car wall is made of non-stainless-steel
	Hairline stainless steel kick plate							Car wall is made of stainless steel
Car floor	Polyvinyl chloride real stone floor							Standard
	Nora rubber floor							Optional
Handrail	Car mode	Wide car series			Deep car series			Optional
	Handrail type Handrail position position position	Front	Side	3 sides	Front	Side	3 sides
	Stainless Steel Round Handrail	Selected			Not provided
	Stainless Steel Flat Handrail	Selected
	Dupont Corian Flat Handrail	Selected			Not provided

CL-1	Elevator Car Ceiling Applicable for wide car
Car Ceiling	Painted Steel Plate*
Lighting	Indirect lighting through milky translucentorganic glass lamp shade.
Ventilation Device	Plastic grill ventilation and cross flow type fan.
Handrail	Stainless Steel Flat Handrail
Car Floor	Nora rubber floor

*Color number is selected and determined according to SMEC decoration color boards.

CL-2	Elevator Car Ceiling Applicable for wide car
Car Ceiling	Mirror plate or titanium platingmirror plate*
Lighting	Indirect lighting through acrylictransparent mirror face plate, translucent mirror face plate, incandescentdirect lighting is fit in four corners.
VentilationDevice	Painted steel plate grillventilation and cross-flow fan.
CarFloor	Parquet marble patternshall be provided by customer.

*Color number is selected and determined according to SMEC decoration color boards.

CL-12	Car Ceiling Applicable for wide car
Car Ceiling	Diamond Silver Metallic Paint Coating StainlessSteel Plate
Lighting	Indirect illumination though two lines offluorescent lamps.
Ventilation Device	Side Air Vent and Cross-flow Fan.
Handrail	Stainless Steel Flat Handrail
Car Floor	Polyvinyl chloride real stone floor

CL-13	Elevator Car Ceiling Applicable for wide car
Car Ceiling	PaintedSteel Plate*
Lighting	Indirectillumination though one to three lines of fluorescent lamps with milky semitransparent organic glass lamp shade.
Ventilation Device	PaintedSteel plate grill ventilation and cross-flow fan.
Handrail	StainlessSteel Flat Handrail
Car Floor	Polyvinylchloride real stone floor

DD-JV-2	Elevator Car Ceiling Applicable for wide car
CarCeiling	PaintedSteel Plate*
Lighting	Full lighting through milkytranslucent aciform organic glass plate and organic glass lamp columns are fiton two sides.
VentilationDevice	SideAir Vent and Cross-flow Fan.
Handrail	Stainless Steel Round Handrail
Car Floor	Parquetmarble pattern shall be provided by customer.

*Color number is selected and determined according to SMEC decoration color boards.

DD-JII-3	Elevator Car Ceiling Applicable for wide car
CarCeiling	MirrorStainless Steel Plate
Lighting	Full lighting through milkytranslucent organic glass plate, incandescent direct lighting is fit in fourcorners.
VentilationDevice	SideAir Vent and Cross-flow Fan.
Handrail	Stainless Steel Round Handrail
Car Floor	Parquetmarble pattern shall be provided by customer.

ZCL-SP01(CAP＜1600kg)	Elevator Car Ceiling Applicable for wide car
CarCeiling	PaintedSteel Plate
Lighting	Full lighting through milkytranslucent organic glass plate, incandescent direct lighting is fit in fourcorners.
VentilationDevice	SideAir Vent and Cross-flow Fan.
Car Floor	Parquetmarble pattern shall be provided by customer.

Color number is selected and determined according to SMEC decoration color boards.

ZCL-SP02(CAP＜1600kg)	Elevator Car Ceiling Applicable for wide car
CarCeiling	PaintedSteel Plate
Lighting	Full lighting through milkytranslucent organic glass plate, incandescent direct lighting is fit in fourcorners.
VentilationDevice	SideAir Vent and Cross-flow Fan.
Car Floor	Parquet marble pattern shall be provided by customer.

*Color number is selected and determined according to SMEC decoration color boards.

ZCL-CP01(CAP＜1600kg) Elevator Car Ceiling
Car Ceiling	Painted Steel Plate(ZY-001)
Lighting	Painted steel plate interspersed by five downlights equipped with energy-saving tube, which possesses obvious effect onenergy saving and avoids high heat from traditional incandescent bulb.
VentilationDevice	Deflection blade guidesthe air volume to center part of car and improves the ventilation effect in carin hot summer.
Handrail	Stainless Steel Flat Handrail
Car Floor	Nora rubber floor
Characteristics	Plane design, which prevents the car beingscratched during furniture moving, is particularly suitable for residentialbuilding.

ZCL-CP02(CAP＜1600kg) Elevator Car Ceiling
Car Ceiling	Painted Steel Plate(ZY-001)
Lighting	Painted steel plate interspersed by six downlights equipped with energy-saving tube, which possesses obvious effect onenergy saving and avoids high heat from traditional incandescent bulb.
Ventilation Device	Deflection blade guides the air volume to center part ofcar and improves the ventilation effect in car in hot summer.
Handrail	Stainless Steel Flat Handrail
Car Floor	Nora rubber floor
Characteristics	Plane design, which prevents the car being scratched during furnituremoving, is particularly suitable for residential building.

CL-4B Elevator Car Ceiling Applicable for 800kg deep car
Car Ceiling	Painted Steel Plate
Lighting	Indirect full lighting through milky translucent organicglass lamp shade.
Ventilation Device	Plastic grill ventilation and cross-flow fan.
Handrail	Stainless Steel Flat Handrail
Car Floor	Polyvinyl chloride real stone floor

*Color number is selected and determined according to SMEC decoration color boards.

CL-4A
Elevator Car Ceiling
Applicable for 630kg deep car

CL-4C
Elevator Car Ceiling
Applicable for 1050kg deep car
