Bus Paint Booth, GL8 Series
Request a Quote
GZ Guangli manufactures larger size paint booths which are suitable for painting and drying of small & mid-size buses and coaches.
Features
- All steel construction raised basement;
- Full downdraft airflow style, ensuring turbulence-free airflow path;
- Illumination brightness reaches 1000 lux;
- Oil fuel heating (gas-fired heating, electric central heating, hot water heating and steam heating are optional);
Specifications
- Exterior dimensions: 8.7×5.63×4.23m
- Interior dimensions: 8.6×4.0×3.4m
- Access door width: 3.0m
- Access door height: 3.35m
- Airflow: 36,000m 3 /h
- Air speed: 0.25-0.35m/s
- Curing temperature: 60℃-80℃
- Power: approx. 21.5kw
- Applicable vehicle: small & mid-size bus
Standard Configurations
- Basement: all steel construction raised basement, full grating (2-row grating 3-row checkered plate is optional);
- Fan unit: one 11kw intake fan, no exhaust fan;
- Heating: Riello G20S oil burner (RG5D oil burner or RS5D gas burner), with heat exchanger;
- Lighting system: upper lights are 12*4*18W LED light tubes, lower lights are 10*4*18W LED light tubes;
- Wall panel: EPS insulated wall panel, thickness 50mm;
- Ceiling structure: welded ceiling frame;
- Roof panel: single-skin galvanized steel roof panel;
- Electric control: phase loss protection, overheat protection and overload protection, reduced-voltage starting of motor;
EPS insulated wall panel Volume control damper (VCD) All steel construction raised basement (2-row grating 3-row checkered plate) European-style fan Electric control panel Ceiling filterRelated products
