GE3236 Raschel Machine

Double needle bar raschel knitting machine for producing multilayer faux fur fabrics

Applications

Multi-layer imitated rabbit fur fabrics used in clothing

Features
  • Multilayer faux fur warp knitting machine uses an oil immersed cam-linkage mechanism and a fixed knock-over comb bar.
  • The spacer fabric warp knitting machine features an easy operation sinker system, allowing automatically adjusting of the distance between knocking over bar, and the ground bar.
  • Raschel warp knitting machine utilizes synchronous belt drive for electronic yarn let-off and electronic fabric take-up.
  • The plush has a pile height of 20-50mm.
Specifications
  • Needle type Individual latch needle, block latch needle
  • Gauge E16, E18, E22
  • Number of bars 6/7 bars
  • Working width 90"/100"/110"/138"
  • Max. speed 500 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE3236-90" 3900×6050×3750 23.6 8000 17
GE3236-100" 4200×6050×3750 25.4 8500 18
GE3236-110" 4550×6050×3750 27.5 10000 18
GE3236-138" 5100×6050×3750 30.8 12000 19
