EMA02 2 Flute Square End Mill, Long Length

EMA02 2 Flute Square End Mill, Long Length
EMA02 2 Flute Square End Mill, Long Length
EMA02 2 Flute Square End Mill, Long Length
EMA02 2 Flute Square End Mill, Long Length
Request a Quote
View All: http://metalworking-tool.com/1-2-ema02-square-2-flutes-long-length.html
  • Specially designed to cut prehardened steel, carbon steel, alloy steel up to HRC56
  • Also suitable for machining stainless steel, titanium, inconel, and other high temperature alloys
  • Excellent for mold & die industry
  • Ideal for high speed cutting, dry and wet cut
  • Oerlikon Balzers coating offers superior hardness and heat resistance
  • Center & slotting cutting
  • Deep slotting is possible by reduced neck
Application
Product Specifications
Coating AITiN /TiALN /TiAISiN
AITiSiN 		HRC HRC46/56
Helix Angle 35°/36°/37° Shank Cylindrical H6
Material IMC™ Carbide Rod Tolerance on Cutting Diameter 0-0.030
Carbide End Mill, Square, 2 Flutes, Long Length (UNT-EMA02)
UNT EDP # Click to Order Mill Dia.
D1 		Shank Dia.
D2 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMA02010075 1.0 4 5 75 2
EMA02015075 1.5 4 6 75 2
EMA02020075 2.0 4 8 75 2
EMA02025075 2.5 4 8 75 2
EMA02030075 3.0 4 10 75 2
EMA02040075 4.0 4 12 75 2
EMA02040100 4.0 4 12 100 2
EMA020100756 1.0 6 5 75 2
EMA020150756 1.5 6 6 75 2
EMA020200756 2.0 6 8 75 2
EMA020250756 2.5 6 8 75 2
EMA020300756 3.0 6 10 75 2
EMA020400756 4.0 6 12 75 2
EMA02050075 5.0 6 16 75 2
EMA02060075 6.0 6 25 75 2
EMA02060100 6.0 6 30 100 2
EMA02080100 8.0 8 35 100 2
EMA02100100 10.0 10 40 100 2
EMA02120100 12.0 12 45 100 2
EMA02060150 6.0 6 35 150 2
EMA02080150 8.0 8 40 150 2
EMA02100150 10.0 10 50 150 2
EMA02120150 12.0 12 50 150 2
EMA02160150 16.0 16 70 150 2
EMA02200150 20.0 20 70 150 2

• End mills with non-standard sizes or specifications not listed above can be customized according to customer needs.
