PET Monofilament Self Closing Sleeving
Request a Quote
Material: PET Monofilament
Working temperature: -40℃-150℃
Melting temperature: 240℃
Edge overlap: ≥75%
Product certification: SGS, UL, DIN5510
Optional filament diameter: 0.25
The PET monofilament self closing sleeving features flame retardant rate of V0, and then naturally wrapped using special technology. The degree of wrapped coverage reaches 75%. This product features an excellent heat dispersion, fire resistance, wear resistance and beautiful appearance. It is convenient for braiding sleeving, and the open structure is beneficial for reassembly, recondition and maintenance of wires.
Application
The PET monofilament self-closing sleeving is usually used in wiring in high speed train system.
| Size and specification | INQUIRY | ||||
| Model | Inner diameter(d) | Edge overlap(%) | Coverage diameter | Package(L) | |
| MX-PJ006 | 6mm | 75% | 6mm | 25m/reel | |
| MX-PJ008 | 8mm | 8mm | 25m/reel | ||
| MX-PJ010 | 10mm | 10mm | 25m/reel | ||
| MX-PJ013 | 13mm | 13mm | 25m/reel | ||
| MX-PJ016 | 16mm | 16mm | 25m/reel | ||
| MX-PJ019 | 19mm | 19mm | 25m/reel | ||
| MX-PJ025 | 25mm | 25mm | 25m/reel | ||
| MX-PJ032 | 32mm | 32mm | 25m/reel | ||
| MX-PJ038 | 38mm | 38mm | 25m/reel | ||
| MX-PJ045 | 45mm | 45mm | 25m/reel | ||
| MX-PJ050 | 50mm | 50mm | 25m/reel | ||
