SD-450Ⅱ-R Automatic Soldering Robot

Request a Quote

View All: http://automated-system.com/1-2-sd-450-automatic-soldering-robot.html

SD-450Ⅱ-R automatic soldering robot adopts six-axis motion control system, which enables two platforms to work together and doubles the operation efficiency. This soldering robot machine has high heating efficiency, fast heating speed and good soldering quality.

Characteristics

The automatic soldering robot has functions of spot welding, drag soldering and automatic cleaning.
The robot has functions of automatic positioning, copying, arrangement and position correction.
Various parameters in the soldering process can be set to guarantee the soldering quality.
The 5 inches touch screen can provide a simple interface, leading to an easy and fast operation.
The slideway and screw is adopted to transmit power, which leads to a high accuracy motion.
The machine adopts automatic solder wire feeding system with editable multi-stage solder wire feeding mode.

Technical parameters

Dimension: 570*550*830mm (L*W*H)
Working range: 460*330*100mm (X*Y*Z)
One-sided working range: 200*330*100mm (X*Y*Z)
Number of platform: 2 (single Y axis operating)
Drive mode: 5 axis precision stepper motor
Position accuracy: ±0.02mm
Position accuracy of R axis: ±0.05°
Program memory: 256 sets, 400 points/set
Temperature control power: 150W/320W
USB port: programs interoperable among many machines.
Power supply: 220V, 50HZ
Air pressure: 0.3MPa
Net weight: 50kg
