This automatic screw capping machine for 1.5L flat bottles and drums can feed in bottles and caps, unscramble caps, cap bottles, and dispense finished bottles. We use international technology to automatically grasp and position caps precisely without damaging them. This efficient capping machine stops operation when it senses it is empty of caps. The bottle capping equipment also sense and removes damaged bottles.

Main performance parameters:
  • Power supply: 220V; 50Hz
  • Power (kW): 1.5KW
  • Air source: 0.6MPa clean and stable air
  • Bottle size: height:80-280mm, width:40-80mm, length:80-120mm
  • Cap diameter: Φ20-Φ70mm
  • Cap height: 15mm-30mm
  • Production capacity: ≤1200BPH
  • Weight: about580kg
  • Dimensions(L x W x H): 2000mm x 1000mm x 1600mm
  • Air consumption: 100(Liter / Minute)
  • Capping head No.: 1
  • Air Pressure: 0.5~0.7 MPA
Features:

1. This capping machine is easy to adjust specifications to the size of the drums and bottles.

2. The machine first clamps then caps so capping is precise and thorough. Pneumatic motor driven capping and speed can be adjusted

3. Sensors detect when the number of caps on hold is low

4. Automatic feeding, capping, and dispensing of containers

Suitable bottles:
Configuration
No. name model ;specification unit quantity note
1 Modeling socket Two-hole unit 1
2 Breaker Single-phase, 16A unit 1 CHNT
3 AC contactor 0910 unit 1 CHNT
4 Relay DC24V; Eight in group unit 1
5 Power switch DC24V;4.2A unit 1
6 PLC S7-200 CN 6ES7 216-2BD23-0XBB unit 1 Siemens
Communication link unit 1
7 Touch screen SA-7B unit 1 Siemens
8 Transducer 220V;0.75KW unit 2 Schneider
220V;0.37KW unit 3 Schneider
9 Button Red unit 1 Schneider
Green unit 1 Schneider
10 Emergency
set 1 Schneider
11 Regulation resistance 2W10K; add the lip set 2
12 Oil-water separator AW4000 (large) unit 1
AW2000 (small) unit 1
13 Manual slide valve MS-44MF unit 1
MS-22MF unit 1
15 Fiber amplifier VRF-N unit 2
16 Fiber NF-TB01 unit 2
17 Air pressure switch HLP-110E unit 1
18 Photoelectric Switch BGS-S08N unit 2
19 Minus variable speed motor NMRV050 0.37KW 1:30 sets 1
20 Cylinder MALΦ32 x 80 unit 2
TN25 x 100 unit 1 Airtac
DNC-80-40-PPV-A unit 1 Festo
DNC-80-100-PPV-A unit 1 Festo
21 Vertical motor YS7124 0.37KW sets 1
