Rotatory Grading Sifter
Description
The SFJH series rotatory grading sifter is mainly composed of V-belt driven weight balance mechanism and elastic supporting mechanism in tail, which can make the materials rotate on the working surface of the horizontal rotating body, so that the sifting efficiency is high and the vibration is low. The interior of the discharge port of the sifter features a streamlined design, which can make the materials not deposit and prevent cross-contamination among different materials.
Application
The rotatory grading sifter is applicable for the grading of pellet materials and crushing materials for feed plants, as well as intermediate products after secondary crushing for large and medium-sized feed plants. In addition, the equipment can also be widely applied to the sifting and grading jobs of raw materials and finished products in grain, food, sugaring and many other industries.
| Model | Power(kw) | Yield(t/h) | Outline size(mm) | |
| Granular | Powdery | |||
| SFJH80×1C | 2.2 | 5-8 | 3-6 | 2793×1200×990 |
| SFJH80×2C | 2.2 | 5-8 | 3-6 | 2881×1290×1112 |
| SFJH80×3C | 2.2 | 5-8 | 3-6 | 2973×1290×1303 |
| SFJH100×1C | 2.2 | 8-13 | 6-10 | 3345×1510×1307 |
| SFJH100×2C | 2.2 | 8-13 | 6-10 | 3433×1510×1307 |
| SFJH100×3C | 2.2 | 8-13 | 6-10 | 3521×1510×1307 |
| SFJH130×2C | 3.0 | 10-16 | 8-14 | 3223×1845×1317 |
| SFJH130×3C | 3.0 | 10-16 | 8-14 | 3489×1845×1317 |
| SFJH150×2C | 3.0 | 20-26 | 18-20 | 4096×1980×1317 |
| SFJH150×3C | 4.0 | 15-18 | 12-16 | 4411×1980×1317 |
| SFJH180×1C | 7.5 | 25-40 | 20-30 | / |
| SFJH180×2C | 7.5 | 25-40 | 20-30 | / |
| SFJH200×1C | 7.5 | 30-48 | 24-36 | / |
| SFJH200×2C | 7.5 | 30-48 | 24-36 | / |
The screen quick release lever is firm and the screen replacement is fast.
Depending on customers’ requests, a single-layer screen, two-layer screen or three-layer screen can be customized.
