NSF Stainless Steel Mini Ball Valve, One-Piece Ball Valve, with Hex Body
Request a Quote
- Threads available with Female x Female or Female x Male
- Working pressure: 1000 psi for 1/8" to 3/8", 800 psi for 1/2"
- Temperature range: -4 °F to 250 °F (-20 °C to 120 °C)
- Material: 316 stainless steel body and cap
- Zinc Alloy wedge, lever and T handle optional
| Part # | Part Name | Material |
| 1 | Body | 316 Stainless Steel |
| 2 | Seat | PTFE |
| 3 | Ball | 316 Stainless Steel |
| 4 | O-Ring | Viton |
| 5 | Cap | 316 Stainless Steel |
| 6 | Stem | 316 Stainless Steel |
| 7 | Stem Bottom Seal | PTFE |
| 8 | Stem Top Seal | PTFE |
| 9 | Screw | 304 Stainless Steel |
| 10 | Handle | Zinc Alloy |
| Stainless Steel Mini Ball Valve with Wedge Handle | Inch/Metric(mm) | |||||
| Item# | Size | d IN(mm) | A IN(mm) | B IN(mm) | C IN(mm) | H IN(mm) |
| 1000SMBV12-WH | 1/8'' F x F | 0.32'' (8) | 1.79''(45.5) | 0.85'' (21.5) | 0.51'' (13) | 1.24'' (31.5) |
| 1000SMBV25-WH | 1/4'' F x F | |||||
| 1000SMBV33-WH | 3/8" F x F | 1.73''(44) | ||||
| 800SMBV50-WH | 1/2" F x F | 0.39'' (10) | 2.11''(53.5) | 1'' (25.5) | 0.59'' (15) | 1.32'' (33.5) |
| 1000SMBV12M-WH | 1/8'' M x F | 0.32'' (8) | 1.79''(45.5) | 0.85'' (21.5) | 0.51''(13) | 1.24''(31.5) |
| 1000SMBV25M-WH | 1/4'' M x F | |||||
| 1000SMBV33M-WH | 3/8" M x F | 1.73''(44) | ||||
| 800SMBV50M-WH | 1/2" M x F | 0.39'' (10) | 2.22'' (56.5) | 1'' (25.5) | 0.59'' (15) | 1.32''(33.5) |
| 1000SMBV12MM-WH | 1/8'' M x M | 0.32'' (8) | 2.17'' (55) | 0.85'' (21.5) | 0.51'' (13) | 1.24'' (31.5) |
| 1000SMBV25MM-WH | 1/4'' M x M | |||||
| 1000SMBV33MM-WH | 3/8" M x M | 2.22''(56.5) | ||||
| 800SMBV50MM-WH | 1/2" M x M | 0.39'' (10) | 2.64'' (67) | 1''(25.5) | 0.73''(18.5) | 1.32'' (33.5) |
| Stainless Steel Mini Ball Valve with T Handle | ||||||
| Item # | Size | d IN(mm) | A IN(mm) | B IN(mm) | C IN(mm) | H IN(mm) |
| 1000SMBV12-TH | 1/8'' F x F | 0.32'' (8) | 1.79''(45.5) | 0.85'' (21.5) | 0.51'' (13) | 1.24'' (31.5) |
| 1000SMBV25-TH | 1/4” F x F | |||||
| 1000SMBV33-TH | 3/8" F x F | 1.73''(44) | ||||
| 800SMBV50-TH | 1/2" F x F | 0.39'' (10) | 2.11''(53.5) | 1'' (25.5) | 0.59'' (15) | 1.32'' (33.5) |
| 1000SMBV12M-TH | 1/8'' M x F | 0.32'' (8) | 1.79''(45.5) | 0.85'' (21.5) | 0.51''(13) | 1.24''(31.5) |
| 1000SMBV25M-TH | 1/4''M x F | |||||
| 1000SMBV33M-TH | 3/8" M x F | 1.73''(44) | ||||
| 800SMBV50M-TH | 1/2" M x F | 0.39'' (10) | 2.22'' (56.5) | 1'' (25.5) | 0.59'' (15) | 1.32''(33.5) |
| 1000SMBV12MM-TH | 1/8'' M x M | 0.32'' (8) | 2.17'' (55) | 0.85'' (21.5) | 0.51'' (13) | 1.24'' (31.5) |
| 1000SMBV25MM-TH | 1/4'' M x M | |||||
| 1000SMBV33MM-TH | 3/8" M x M | 2.22''(56.5) | ||||
| 800SMBV50MM-TH | 1/2" M x M | 0.39'' (10) | 2.64'' (67) | 1''(25.5) | 0.73''(18.5) | 1.32'' (33.5) |
| Stainless Steel Mini Ball Valve with Lever Handle | ||||||
| Item # | Size | d IN(mm) | A IN(mm) | B IN(mm) | C IN(mm) | H IN(mm) |
| 1000SMBV12-LH | 1/8'' F x F | 0.32'' (8) | 1.79''(45.5) | 0.85'' (21.5) | 0.51'' (13) | 1.24'' (31.5) |
| 1000SMBV25-LH | 1/4'' F x F | |||||
| 1000SMBV33-LH | 3/8" F x F | 1.73''(44) | ||||
| 800SMBV50-LH | 1/2" F x F | 0.39'' (10) | 2.11''(53.5) | 1'' (25.5) | 0.59'' (15) | 1.32'' (33.5) |
| 1000SMBV12M-LH | 1/8'' M x F | 0.32'' (8) | 1.79''(45.5) | 0.85'' (21.5) | 0.51''(13) | 1.24''(31.5) |
| 1000SMBV25M-LH | 1/4'' M x F | |||||
| 1000SMBV33M-LH | 3/8" M x F | 1.73''(44) | ||||
| 800SMBV50M-LH | 1/2" M x F | 0.39'' (10) | 2.22'' (56.5) | 1'' (25.5) | 0.59'' (15) | 1.32''(33.5) |
| 1000SMBV12MM-LH | 1/8” M x M | 0.32'' (8) | 2.17'' (55) | 0.85'' (21.5) | 0.51'' (13) | 1.24'' (31.5) |
| 1000SMBV25MM-LH | 1/4'' M x M | |||||
| 1000SMBV33MM-LH | 3/8" M x M | 2.22''(56.5) | ||||
| 800SMBV50MM-LH | 1/2" M x M | 0.39'' (10) | 2.64'' (67) | 1''(25.5) | 0.73''(18.5) | 1.32'' (33.5) |
