Marine Loading Arm (Single Arm)

Request a Quote

View All: http://loadingarmsystem.com/2-1-marine-loading-arm-single-arm.html

This product has been discontinued and removed from our shelves.

This marine loading arm is mainly used to transfer liquids between ship and shore, primarily suited for the loading and unloading of gasoline, diesel and other low-volatility media.

Operating method: manually operated, hydraulically operated
Supporting structure: independent support, hybrid support, self support

Specifications

Nominal diameter: DN100～DN400 (4"～16")
Design pressure: -0.06MPa～4.0MPa
Design temperature: -196℃～ 230℃
Pipeline material: carbon steel/stainless steel/PTFE lined steel

Features

Simple to use;
Easy replacement of seals;
Light weight;
Less space required on the jetty;
Low wind loads;
Designed with large working envelope that can satisfy large vessels and ships' loading and unloading needs;
Configured with locking mechanism, allowing the loading arm to be in a locked condition when it is not working;
Cable & wheel counterweight balancing system enables the loading arm to be balanced in any motion within the working envelope while lowering the height of the center of gravity thereby improving the stability;

Optional Accessories

Vacuum breaker
Draining system
Insulating flange
Adjustable support leg
Emergency release coupling (ERC)
Manual quick connect-disconnect coupler (QCDC)
Hydraulic quick connect-disconnect coupler (QCDC)
Position monitoring system
