Pure steam generator

Request a Quote

View All: http://pharm-equipment.com/2-3-pure-steam-generator.html

The pure steam generator produces pyrogen-free high purity steam for sterilization. Pure steam can also effectively prevent the secondary contamination caused by heavy materials, heat sources, and other materials. Thus, this equipment is widely applicable to pharmaceuticals, medical treatment, food and other industries.

Main features

Pure steam generators come in three options of fully-automatic, semi-automatic and manual.
The evaporators are all made of seamless stainless steel tube.
Pure steam generator housing features good heat preservation, low thermal loss and high thermal efficiency.
Feedwater inlet can be adjusted manually according to the temperature variation of the steam. By adjusting outlet valve, pure steam of different back pressures and capacities is obtained.
This steam generator has novel design, compact structure, small footprint, convenient operation, flexible adjustability and simple installation.

Technical specs

Model	Power (kW)	Capacity (L/h)	Plant steam inlet (kg/h)	Feedwater inlet (kg/h)	Overall size (mm)
IV-100	0.75	≥100	125	120	1150×550×2600
IV-200	0.75	≥200	250	240	1150×900×2700
IV-300	0.75	≥300	375	360	1400×900×2700
IV-400	0.75	≥400	500	480	1400×950×2700
IV-500	0.75	≥500	630	600	1500×1050×2900
IV-600	0.75	≥600	755	720	1600×1100×2900
IV-700	0.75	≥700	875	840	1700×1100×2900
IV-800	0.75	≥800	1005	960	1750×1100×3000
IV-1000	1.1	≥1000	1260	1200	1750×1100×3000
IV-1500	1.1	≥1500	1890	1800	1850×1200×3200
IV-2000	1.1	≥2000	2500	2400	2350×1250×3300
