VRV Air Conditioner, 25.2kW-200kW Variable Refrigerant Volume Air Conditioner

Request a Quote

View All: http://ruidonghvac.com/2-3-vrv-air-conditioning-system/index.html

The rooftop split air conditioning unit is an energy-efficient air conditioning system specially designed for commercial use. The air conditioner is suitable for use in hotels, supermarkets, office buildings, and many other large scale places.

Technical Parameters

Model			RDVRV025CO	RDVRV028CO	RDVRV034CO	RDVRV040CO	RDVRV045CO	RDVRV050CO	RDVRV056CO	RDVRV062CO
Cooling capacity		kW	25	28	33.5	40	45	50	56	61.5
Heating capacity		kW	27	31.5	37.5	45	50	56	63	69
Power supply			380v/3ph/50hz/60hz
Rated input	Cooling	kW	6.12	7.09	8.63	10.67	12.64	14.16	15.56	16.71
	Heating	kW	6.07	7.02	8.6	10.58	12.6	14.12	15.52	16.65
Rated current	Cooling	kW	12.5	13.4	16.4	19.6	24.1	30.5	35.2	40
	Heating	kW	13.6	13.9	16.7	20	24	30.1	34.9	35
Refrigerant	Type		R410A
	Charge qty.	kg	8		10	12		16
Compressor	Brand/Type		Hitachi/Scroll
	Qty.		1					2
Fan	Type		Axial
	Qty.		1					2
	Motor type		DC
Airflow		m³/h	12000			13980		18780	20820	22020
Connection pipe	Liquid pipe		∮12.7					∮15.88
	Gas pipe		22.23		25.4	28.58
	Connection method		Weldi.g
ESP		Pa	0-80
Sound level		dB(A)	45-57			45-59		45-62		45-63
Net dimension		mm	9308601710			12408601710		15008601710
Note:
			1. Operating temperature for cooling ranges from -5℃ to 52℃; for heating ranges from -20℃ to 24℃.
			2. Cooling data above is obtained in the indoor condition of DB 27℃/ WB 19℃ and outdoor condition of DB 35℃.
			3. Heating data above is obtained in the indoor condition of DB 20℃/ WB 15℃ and outdoor condition of DB 7℃.
			4. Sound level data is obtained at a distance of 1m from the unit.
			5. The above data may be changed without any notice for future improvement.

ROUND-WAY TYPE		MODEL	RDVRV028CI-R	RDVRV036CI-R	RDVRV045CI-R	RDVRV050CI-R	RDVRV056CI-R	RDVRV063CI-R	RDVRV071CI-R	RDVRV080CI-R	RDVRV090CI-R	RDVRV100CI-R	RDVRV112CI-R	RDVRV125CI-R	RDVRV140CI-R	RDVRV160CI-R
Cooling capacity		kW	2.8	3.6	4.5	5.0	5.6	6.3	7.1	8.0	9.0	10.0	11.2	12.5	14.0	16.0
Heating capacity		kW	3.2	4.0	5.0	5.6	6.3	7.1	8.0	9.0	10.0	11.2	12.5	14.0	16.0	18.0
Power supply			220V/1Ph/50Hz
Power input		W	55		70		75		90		150			190		210
Fan type			Axial
Fan motor	Power output	W	26		30				37		50		65
Fan speed	H	rpm	490		580				670		590		630			630
	M	rpm	400		490				600		500		590			590
	L	rpm	340		410				500		425		480			480
	SL	rpm	300		360				400		350		420			420
Air flow	H	m³/h	750	810	900	900	960	960	1020	1200	1500	1620	1700	1800	1800	2100
	M	m³/h	660	690	720	720	780	780	900	1080	1200	1260	1360	1500	1500	1800
	L	m³/h	540	540	600	600	600	600	690	870	900	1020	1080	1200	1200	1500
Sound level	H	dB(A)	32	32	36	36	36	36	39	39	42	42	42	44	44	44
	M	dB(A)	30	30	33	33	33	33	36	36	39	39	39	40	40	40
	L	dB(A)	25	25	31	31	31	31	33	33	35	35	35	35	35	35
Connection pipe	Liquid pipe	mm	∮6.35						∮9.52
	Gas pipe	mm	∮12.7						∮15.88
Drian pipe	Ex-diameter	mm	DN25
Net dimension	Body	mm	840840230
	Panel	mm	95095050
Net weight	Body	kg	23		25						30				32
	Panel	kg	6
Accessories	Plenum box		X
	Air filter		√
	Built-in electronic expansion valve		√
	Drain pump		√
	AC motor		√
	DC motor		X
	Remote controller		Optional
	Wire controller		Optional
	Centralized controller		Optional

2-WAY TYPE		MODEL	RDVRV028CI-2	RDVRV036CI-2	RDVRV045CI-2	RDVRV056CI-2	RDVRV071CI-2	RDVRV080CI-2	RDVRV090CI-2	RDVRV100CI-2	RDVRV112CI-2	RDVRV125CI-2	RDVRV140CI-2
FOB Price		USD	437	442	464	467	512	528	622	643	673	678	682
Cooling capacity		kW	2.8	3.6	4.5	5.6	7.1	8.0	9.0	10.0	11.2	12.5	14.0
Heating capacity		kW	3.2	4.0	5.0	5.6	8.0	9.0	10.0	11.2	12.5	14.0	16.0
Power supply			220V/1Ph/50Hz
Power input		W	60	62	68	85	94	98	129	135	175	185	268
Fan type			Centrifugal
Fan motor	Power output	W	10	12	16	25	30	30	20*2	25*2	30*2	45*2	45*2
Connection pipe	Liquid pipe	mm	∮6.35				∮9.52
Connection pipe	Gas pipe	mm	∮12.7				∮15.88
Drian pipe	Ex-diameter	mm	DN20
Net dimension	Body	mm	840520315		960520315		1200520315		1680520315
Net dimension	Panel	mm	108363033		120363033		144363033		192363033
Net weight		kg	32	32	37	37	40	40	45	45	47	47	47
Accessories	Plenum box		X
	Air filter		√
	Built-in electronic expansion valve		√
	Drain pump		√
	AC motor		√
	DC motor		X
	Remote controller		O
	Wire controller		O
	Centralized controller		O

1-WAY TYPE		MODEL	RDVRV028CI-1	RDVRV036CI-1	RDVRV045CI-1	RDVRV056CI-1	RDVRV071CI-1
FOB PRICE		USD	330	354	388	468	495
Cooling capacity		kW	2.8	3.6	4.5	5.6	7.1
Heating capacity		kW	3.2	4.0	5.0	6.3	8.0
Power supply			220V/1Ph/50Hz
Power input		W	40		45		50
Fan type			Centrifugal
Fan motor	Power output	W	10	18	25	30	30
Air flow	H	m³/h	510	600	720	910	1000
	M	m³/h	410	480	570	830	850
	L	m³/h	310	360	450	700	750
Sound level	H	dB(A)	36	38	42	45	47
	M	dB(A)	34	28	39	41	43
	L	dB(A)	30	26	35	39	40
Connection pipe	Liquid pipe	mm	∮6.35				∮9.52
	Gas pipe	mm	∮12.7				∮15.88
Drian pipe	Ex-diameter	mm	DN20
Net dimension	Body	mm	870460250			1180495290
	Panel	mm	107052033			138055033
Net weight		kg	25	27		39
Accessories	Plenum box		X
	Air filter		√
	build-in EXV		O (external)
	Drain pump		√
	AC motor		√
	DC motor		X
	Remote controller		O
	Wire controller		O
	Centralized controller		O

Features

Energy saving. Hitachi variable frequency scroll type compressor realizes 27 level capacity regulating and energy output as needed. It is highly efficient and cost effective.
Easy installation. It can be installed on balconies, rooftops or ground level. Exclusive machine room or special foundation are not necessary for the air conditioning system. Installation is easy and simple.
Ruidong RJV-V series central air-conditioning systems adopt high-accuracy proportion integration differentiation (PID) for control. By the accurate measurement of sensors, the running of variable speed compressors and pulse width modulation (PMW) are consistently controlled to adjust the flow of cold media.
Quick cooling and heating capacity. The temperature difference from setting temperature is within ±0.5℃.
The cold media pipe can be as long as 175m. The vertical elevation for the indoor and outdoor unit of the same system can be up to 50m. Indoor unit has an elevation difference up to 30m. The distance between the first branch and indoor unit is 40m.
Low noise during operation. Scroll type exhaust fan.
