Water Flow Servo Valve
Request a Quote
The water flow servo valve is an excellent option for water heater and fireplaces. In the servo system, a controller sends a command to start motor drive in response to the water flow rate. Using the servo motor, the water flow is adapted to meet specific application needs. The servo valve solves problems that a current water flow sensor cannot in adjusting the water flow rate.
SCG-1-S70 Water Flow Servo Valve
| Operating voltage | 5V-12V DC |
| Maximum operating current | 25mA(DC 12V)/15mA(DC 5V) |
| Load capacity | ≤15mA DC12≤10mA DC5(RPLUS=1kΩ) |
| Start flow | ≤1.5L/min |
| Flow pulse characteristics | f=8.1Q-3(f Frequency HZ, Q Flow L/min) |
| Accuracy(flow rate-pulse output) | 3-17L/min±10% |
| Allowable pressure resistance | ≤1.75Mpa |
SCG-2-S70 Water Flow Servo Valve
| Operating voltage | 5V-12V DC |
| Maximum operating current | 25mA(DC 12V)/15mA(DC 5V) |
| Load capacity | ≤15mA DC12≤10mA DC5(RPLUS=1kΩ) |
| Start flow | ≤1.5L/min |
| Flow pulse characteristics | f=8.1Q-3(f Frequency HZ, Q Flow L/min) |
| Accuracy(flow rate-pulse output) | 3-17L/min±10% |
| Allowable pressure resistance | ≤1.75Mpa |
SCG-1-S108 Water Flow Servo Valve
| Operating voltage | 5V-12V DC |
| Maximum operating current | 25mA(DC 12V)/15mA(DC 5V) |
| Load capacity | ≤15mA DC12≤10mA DC5(RPLUS=1kΩ) |
| Start flow | ≤1.5L/min |
| Flow pulse characteristics | f=8.1Q-3(f Frequency HZ, Q Flow L/min) |
| Accuracy(flow rate-pulse output) | 3-17L/min±10% |
| Allowable pressure resistance | ≤1.75Mpa |
SCG-1-S31 Water Flow Servo Valve
| Operating voltage | 5V-12V DC |
| Maximum operating current | 25mA(DC 12V)/15mA(DC 5V) |
| Load capacity | ≤15mA DC12≤10mA DC5(RPLUS=1kΩ) |
| Start flow | ≤1.5L/min |
| Flow pulse characteristics | f=8.1Q-3(f Frequency HZ, Q Flow L/min) |
| Accuracy(flow rate-pulse output) | 3-17L/min±10% |
| Allowable pressure resistance | ≤1.75Mpa |
SCG-1-S101 Water Flow Servo Valve
| Operating voltage | 5V DC |
| Maximum operating current | 25mA(DC 12V)/15mA(DC 5V) |
| Load capacity | ≤10mA DC5V(RPLUS=1kΩ) |
| Start flow | ≤1.5L/min |
| Flow pulse characteristics | f=8.1Q-3(f Frequency HZ, Q Flow L/min) |
| Accuracy(flow rate-pulse output) | 3-17L/min±10% |
| Allowable pressure resistance | ≤1.75Mpa |
SCG-1-S116 Water Flow Servo Valve
| Operating voltage | 5V DC |
| Maximum operating current | 25mA(DC 12V)/15mA(DC 5V) |
| Load capacity | ≤10mA DC5V(RPLUS=1kΩ) |
| Start flow | ≤1.5L/min |
| Flow pulse characteristics | f=8.1Q-3(f Frequency HZ, Q Flow L/min) |
| Accuracy(flow rate-pulse output) | 3-17L/min±10% |
| Allowable pressure resistance | ≤1.75Mpa |
SCG-1-T98 Water Flow Servo Valve
| Operating voltage | 5V DC |
| Maximum operating current | 5mA（DC5V） |
| Load capacity | ≤10mA DC5V(RPLUS=1kΩ) |
| Start flow | ≤1.5L/min |
| Flow pulse characteristics | f=8.1Q-3(f Frequency HZ, Q Flow L/min) |
| Accuracy(flow rate-pulse output) | 3-17L/min±10% |
| Allowable pressure resistance | ≤1.75Mpa |
SCG-1-S111 Water Flow Servo Valve
| Operating voltage | 5V DC |
| Maximum operating current | 5mA（DC5V） |
| Load capacity | ≤10mA DC5V(RPLUS=1kΩ) |
| Start flow | ≤1.5L/min |
| Flow pulse characteristics | f=8.1Q-3(f Frequency HZ, Q Flow L/min) |
| Accuracy(flow rate-pulse output) | 3-17L/min±10% |
| Allowable pressure resistance | ≤1.75Mpa |
