Rotary Drum Dryer

Series HZG

Weiying offers the HZG series rotary drum dryer to handle your various drying needs in industrial, agricultural, and multiple applications.

Applications
  • Drying material of large particles in the chemical, mining, metallurgy and other industries, including but not limited to blast furnace slag, coal, metal powder, phosphate fertilizer and ammonium sulfide;
  • Drying of powder and granules, such as: HP foaming agent, wine lees slag, light calcium carbonate, active white clay, magnetic powder, graphite, and pharmaceutical slag;
  • Drying of the materials that require low temperature drying and large batch continuous drying;
Features
  • The highly mechanized rotary drum dryer with a large production capacity;
  • This rotary drum dryer has been improved for energy-efficient applications with low resistance, particularly in the mineral and chemical industries;
  • Insensitive to changes in the particle size;
  • Stronger adaptability to a variety of materials and tolerance to operating faults;
  • The specific electricity consumption of the rotary drum dryer is relatively low;
Technical Data
Model Direct heating (co-current flow) Direct heating (co-current flow) Direct heating (counter-current flow) Direct heating (counter-current flow) Indirect heating Indirect heating
Type of material Ore HP blowing agent BLAST furnace slag Ammonium sulfate Phosphate fertilizer Coal
Amount to be treated (kg/h) 1000 466 15000 20000 12000 5000
Primary content of water (%) 30 13 6 1.5 5 6.5
Final content of water (%) 15 0.3 1 0.1 0.1 0.1
Average diameter (mm) 6.5 0.05 4.7 0.5-1.7 0.5 5
Bulk density of raw material (kg/m3) 770 800 1890 1100 1500 750
Amount of hot air (kg/h) 3900 5400 10750 9800 6500 16000
Temperature of air at inlet (℃) 600 165 500 180 650 570
Temperature of raw material (℃) 42 100 70 80 75
Heating way Gas Steam electric heating Heavy oil Coal hot air furnace Heavy oil Heavy oil
Loading coefficient 6.3 7 7.5 7.8 18
Rotating speed (rpm) 4 4 3.5 3 4 2
Gradient 0.04 0.005 0.03 0.05 0.05 0.043
Diameter of dryer 12 24 12 22 Interior drum 8
 Interior drum 16
6 12
Amount of blade (m) 2.0 1.5 2 2.3 Exterior drum 2
Interior drum 0.84
Exterior drum 2.4
Interior drum 0.95
Length of dryer (m) 20 12 17 15 10 16
Drive power (kW) 22 7.5 15 11 11 15

Weiying is a company dedicated to providing custom engineered filtration and drying equipment for the pharmaceutical, chemical, fine chemical and food industries.
