Drum Screen
Request a Quote
Drum screens are usually set up in upstream processes for waste sorting systems, as a first step. These screens sort materials based on their size using different mesh sizes, and here at Jiarun, we custom design drum screens according to customer requirements.
Structures
- The frame is made of a strong, durable stainless steel to ensure a smooth operation and dust free operating environment.
- The roller is made of a strong, high carbon steel board that is shock resistant. It is available in different diameters according to customer requirements.
- All drive and support structure surfaces feature a plastic coating to ensure the mesh works without problems, even at a high speed.
Parameters
| Type | Drum size | Screen panel thickness (mm) | Mesh size | ||||
| Drum diameter (mm) | Drum length (mm) | First section (mm) | Second section (mm) | Third section (mm) | Forth section (mm) | ||
| GT0935 | 900 | 3500 | 6 | 12 | 80 | ||
| GT0945 | 900 | 4500 | 6 | 12 | 40 | 80 | |
| GT1245 | 1200 | 4500 | 6 | 12 | 40 | 80 | |
| GT1260 | 1200 | 6000 | 6 | 12 | 30 | 50 | 80 |
| GT1560 | 1500 | 6000 | 6 | 12 | 30 | 50 | 80 |
| GT1890 | 1800 | 9000 | 8 | 12 | 30 | 50 | 80 |
